Image preview - the first page of the document

>> Download PB documenatation <<

Text preview - extract from the document

F BRAKES

SECTION
PARKING BRAKE SYSTEM
PB B

E
CONTENTS
PREPARATION .......................................................... 2
. PARKING BRAKE SHOE .......................................... 6 . PB
Commercial Service Tools ....................................... 2. Removal and Installation ......................................... 6
.
PARKING BRAKE SYSTEM ..................................... 3 . COMPONENTS .................................................... 6
.
On-Vehicle Service .................................................. 3
. REMOVAL ............................................................ 6
. G
PEDAL STROKE .................................................. 3. INSPECTION AFTER REMOVAL ........................ 7 .
INSPECTION ....................................................... 3
. INSTALLATION .................................................... 7
.
ADJUSTMENT ..................................................... 3
. SERVICE DATA AND SPECIFICATIONS (SDS) ....... 9 .
H
PARKING BRAKE CONTROL .................................. 4 . Parking Drum Brake ................................................ 9
.
Components ............................................................ 4
. Parking Brake Control ............................................. 9
.
Removal and Installation ......................................... 4
.
REMOVAL ............................................................ 4
. I
INSTALLATION .................................................... 5
.

Revision: September 2006 PB-1 2007 Pathfinder
PREPARATION

PREPARATION PFP:00002

Commercial Service Tools EFS0064A

Tool number Description
(Kent-Moore No.)
Tool name
-- Measuring rear rotor drum to parking
(J-21177-A) brake shoe clearance
Brake drum clearance gauge

WFIA0167E

Power tool Loosening bolts and nuts

PBIC0190E

Revision: September 2006 PB-2 2007 Pathfinder
PARKING BRAKE SYSTEM

PARKING BRAKE SYSTEM PFP:36010
A
On-Vehicle Service EFS0064B

PEDAL STROKE
G When parking brake pedal is operated with the specified force, make sure the stroke is within the specified B
number of notches. Check by listening and counting the ratchet clicks.
Pedal stroke : 4 - 5 notches [under force of 196 N (20.0 kg-f, 44.1 lb-f)]
C
INSPECTION
G Make sure the components are attached properly, checking for looseness or backlash.
G Check parking brake pedal assembly for bends, damage and cracks, and replace if necessary. D
G Check cable for wear and damage, and replace if necessary.
G Check parking brake warning lamp switch for malfunction, and replace if necessary. Refer to DI-31, "Wir-
ing Diagram -- WARN --" . E
ADJUSTMENT
1. Remove lower instrument panel LH. Refer to IP-14, "LOWER INSTRUMENT PANEL LH" .
2. Partially engage parking brake pedal to access adjusting nut. PB
3. Insert a deep socket wrench to rotate adjusting nut and loosen
cable until tension is sufficiently released. Then, disengage the
parking brake pedal. G

I
WFIA0165E

4. Remove the wheel and tire using power tool. J
5. Remove the rotor and measure inner diameter at widest point
using Tool.
K
Tool number : -- (J-21177-A)
6. Transfer measurement less 0.6 mm to the parking brake shoes
and adjust accordingly. L
7. Using wheel nuts, secure the disc to the hub to prevent it from
tilting.
8. Rotate disc rotor to make sure there is no drag. M
9. Adjust cable as follows:
a. Operate pedal 10 or more times with a force of 490 N (50 kg-f,
110 lb-f).
b. Rotate adjusting nut with deep socket to adjust pedal stroke to
specification.
Pedal stroke : 4 - 5 notches [under force of
196 N (20.0 kg-f, 44.1 lb-f)]
c. With parking brake pedal completely disengaged, make sure
there is no drag on the parking brake.

WFIA0166E

Revision: September 2006 PB-3 2007 Pathfinder
PARKING BRAKE CONTROL

PARKING BRAKE CONTROL PFP:36010

Components EFS0064C

LFIA0229E

1. Lock plate 2. Pedal assembly 3. Adjusting nut
4. Left rear cable 5. Right rear cable 6. Pin
7. Return spring 8. Equalizer 9. Front cable grommet
10. Front cable

Removal and Installation EFS0064D

REMOVAL
1. Remove the lower instrument panel LH and center console. Refer to IP-14, "LOWER INSTRUMENT
PANEL LH" and IP-16, "CENTER CONSOLE" .
2. Remove the floor trim. Refer to EI-30, "FLOOR TRIM" .
3. Remove the parking brake control adjusting nut.

Revision: September 2006 PB-4 2007 Pathfinder
PARKING BRAKE CONTROL

CAUTION:
Do not reuse adjusting nut after removing it. A
4. Remove the lock plate from the front cable.
5. Remove front parking brake cable bolt and nut.
6. Disconnect return spring from equalizer. B
7. Disconnect the front parking brake cable from the equalizer and remove front cable.
8. Remove the rear disc rotors. Refer to BR-31, "Removal and Installation of Brake Caliper and Disc Rotor" .
C
9. Remove parking brake shoes, and remove rear cable from toggle lever. Refer to PB-6, "PARKING BRAKE
SHOE" .
10. Remove equalizer from right and left rear cables.
D
11. Remove right and left rear cable bolts and nuts, then remove right and left rear cables.
INSTALLATION
G Installation is in the reverse order of removal. E
CAUTION:
Do not reuse adjusting nut after removing it.
G Adjust parking brake. Refer to PB-3, "ADJUSTMENT" . PB

Revision: September 2006 PB-5 2007 Pathfinder
PARKING BRAKE SHOE

PARKING BRAKE SHOE PFP:44060

Removal and Installation EFS0064E

COMPONENTS

LFIA0230E

1. Back plate 2. Anchor 3. Shoes
4. Toggle lever 5. Upper return spring 6. Shoe hold-down spring
7. Retainer 8. Shoe hold-down pin 9. Adjuster
10. Lower return spring 11. Disc rotor 12. Adjuster access plug

REMOVAL
WARNING:
Clean the brakes with a vacuum dust collector to minimize the hazard of airborne particles or other
materials.
NOTE:
Remove the disc rotor only with the parking brake pedal completely disengaged.

Revision: September 2006 PB-6 2007 Pathfinder
PARKING BRAKE SHOE

1. Remove the rear disc rotor. Refer to BR-31, "Removal and Installation of Brake Caliper and Disc Rotor" .
2. Remove the rear drive shaft. Refer to RAX-7, "Removal and Installation" . A
3. Disconnect wheel sensor at harness connector. Then remove wheel sensor wire from grommet mounts.
4. Remove wheel hub and bearing assembly. Refer to RAX-5, "Removal and Installation" .
B
G Withdraw wheel sensor harness through back plate when removing wheel hub and bearing assembly.

5. Remove the return springs.
6. Remove the adjuster. C
7. Remove the retainers, anti-rattle pins and shoes.
8. Disconnect the parking brake cable from the toggle lever.
9. Remove back plate. D
INSPECTION AFTER REMOVAL
Lining Thickness Inspection
E
G Check thickness of lining.
Standard thickness "A" : 5.15
