Image preview - the first page of the document
RSU

>> Download RSU documenatation <<

Text preview - extract from the document

E SUSPENSION

SECTION RSU
REAR SUSPENSION
B

RSU
CONTENTS
PRECAUTIONS ......................................................... 2
. REMOVAL .......................................................... 13 . F
Precautions for Supplemental Restraint System INSTALLATION .................................................. 13 .
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN- Inspection .............................................................. 13
.
SIONER" ................................................................. 2
. SUSPENSION ARM ................................................. 14 . G
Precautions for Rear Suspension ........................... 2 . Removal and Installation ....................................... 14 .
PREPARATION .......................................................... 3
. REMOVAL .......................................................... 14 .
Commercial Service Tools ....................................... 3 . INSPECTION AFTER REMOVAL ...................... 15 .
H
NOISE, VIBRATION, AND HARSHNESS (NVH) INSTALLATION .................................................. 15 .
TROUBLESHOOTING ............................................... 4 . FRONT LOWER LINK ............................................. 16 .
NVH Troubleshooting Chart .................................... 4 . Removal and Installation ....................................... 16 .
REAR SUSPENSION ASSEMBLY ............................ 5 . REMOVAL .......................................................... 16 . I
Components ............................................................ 5
. INSPECTION AFTER REMOVAL ...................... 17 .
On-Vehicle Inspection ............................................. 5. INSTALLATION .................................................. 17 .
Wheel Alignment Inspection .................................... 6 . REAR LOWER LINK & COIL SPRING .................... 18 . J
PRELIMINARY INSPECTION .............................. 6 . Removal and Installation ....................................... 18 .
GENERAL INFORMATION AND RECOMMEN- REMOVAL .......................................................... 18 .
DATIONS ............................................................. 6
. INSPECTION AFTER REMOVAL ...................... 18 .
K
THE ALIGNMENT PROCESS ............................. 7 . INSTALLATION .................................................. 19 .
CAMBER .............................................................. 7
. STABILIZER BAR .................................................... 20 .
TOE-IN ................................................................. 7
. Removal and Installation ....................................... 20 .
REAR SUSPENSION MEMBER ................................ 9 . REMOVAL .......................................................... 20 . L
Removal and Installation ......................................... 9 . INSPECTION AFTER REMOVAL ...................... 20 .
COMPONENTS ................................................... 9 . INSTALLATION .................................................. 20 .
REMOVAL ............................................................ 9
. SERVICE DATA AND SPECIFICATIONS (SDS) ..... 21 . M
INSPECTION AFTER REMOVAL .......................11 . Wheel Alignment ................................................... 21 .
INSTALLATION .................................................. 12 . Ball Joint ................................................................ 22
.
SHOCK ABSORBER ............................................... 13 . Wheelarch Height (Unladen* ) ............................... 22 .
Removal and Installation ....................................... 13 .

Revision: September 2006 RSU-1 2007 Pathfinder
PRECAUTIONS

PRECAUTIONS PFP:00001

Precautions for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT
BELT PRE-TENSIONER" EES002BM

The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SRS and SB section of this Service Man-
ual.
WARNING:
G To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
in the event of a collision which would result in air bag inflation, all maintenance must be per-
formed by an authorized NISSAN/INFINITI dealer.
G Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and Air
Bag Module, see the SRS section.
G Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
Service Manual. SRS wiring harnesses can be identified by yellow and/or orange harnesses or
harness connectors.
Precautions for Rear Suspension EES00238

G When installing the rubber bushings, the final tightening must be done under unladen condition and with
the tires on level ground. Oil will shorten the life of the rubber bushings, so wipe off any spilled oil immedi-
ately.
G Unladen condition means the fuel tank, engine coolant and lubricants are at the full specification. The
spare tire, jack, hand tools, and mats are in their designated positions. There are no passengers in the
vehicle.
G After installing suspension components, check the wheel alignment.
G Caulking nuts are not reusable. Always use new caulking nuts for installation. New caulking nuts are pre-
oiled, do not apply any additional lubrication.

Revision: September 2006 RSU-2 2007 Pathfinder
PREPARATION

PREPARATION PFP:00002
A
Commercial Service Tools EES00239

Tool name Description
Power tool Removing bolts and nuts B

PBIC0190E
D

RSU

Revision: September 2006 RSU-3 2007 Pathfinder
Symptom
