Image preview - the first page of the document
>> Download BRM documenatation <<
Text preview - extract from the document
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY
A
SECTION BRM BODY REPAIR
B
C
D
E
CONTENTS
SERVICE INFORMATION ........................... 2
. Body Sealing ..........................................................12
. F
Body Construction ..................................................16
.
BODY REPAIR ................................................... 2
. Body Alignment ......................................................16
.
Body Exterior Paint Color ......................................... 2
. Handling Precaution for Plastics .............................31 . G
Body Component Parts ............................................ 3
. Precaution in Repairing High Strength Steel ..........34 .
Body Mounting ......................................................... 8
. Foam Repair ...........................................................36
.
Corrosion Protection ................................................ 9
. Replacement Operation ..........................................39 .
H
I
J
BRM
L
M
N
O
P
BRM-1
BODY REPAIR
< SERVICE INFORMATION >
SERVICE INFORMATION
BODY REPAIR
Body Exterior Paint Color INFOID:0000000001697780
LIIA1735E
Color
A15 B25 BW9 C43 E50 Q50 K12 K27 KH3 QM1
code
De- Silver-
Red Majestic Desert White Silver Storm Super Ava-
scrip- ton Mocha
Brawn Blue Stone Frost Lightning Gray Black lanche
Component tion Blue
Paint
PM PM PM M M P M M 2S S
type
Clear
t t t t t t t t t t
coat
Out- Body
A15 B25 BW9 C43 E50 Q50 K12 K27 KH3 QM1
1 side color
mirror XE Black KH3 KH3 KH3 KH3 KH3 KH3 KH3 KH3 KH3 KH3
Side
Guard Body
2 A15 B25 BW9 C43 E50 Q50 K12 K27 KH3 QM1
Mold- color
ing
Bump Fas- Body
3 A15 B25 BW9 C43 E50 Q50 K12 K27 KH3 QM1
ers cias color
Out-
side Body
4 A15 B25 BW9 C43 E50 Q50 K12 K27 KH3 QM1
han- color
dles
Cen-
ter Chro-
Radia- and mium Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P
5 tor em- plate
grille blem
Cen-
Black KH3 KH3 KH3 KH3 KH3 KH3 KH3 KH3 KH3 KH3
ter
Li-
cense Chro-
6 Lamp mium Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P Cr2P
Finish- plate
er
M: Metallic; S: 1-Coat Solid; 2S: 2-Coat Solid, 2P: 2-Coat Pearl; PM: Pearl + Metallic
BRM-2
BODY REPAIR
< SERVICE INFORMATION >
Body Component Parts INFOID:0000000001697781
A
UNDERBODY COMPONENT PARTS
B
C
D
E
F
G
H
I
J
BRM
L
M
N
O
P
LIIA1787E
1. Rear floor side RH
2. Rear floor
3. Storage bin
4. Second seat mounting crossmember
BRM-3
BODY REPAIR
< SERVICE INFORMATION >
5. Rear floor front
6. Center pillar crossmember assembly
7. Front seat mounting rear crossmember
8. Front floor
9. Front seat mounting crossmember
10. Second crossmember extension
11. Front floor reinforcement
12. Side dash RH
13. Lower dash
14. Wash tank bracket
15. Hoodledge reinforcement RH
16. Hoodledge plate
17. Hoodledge RH
18. Hoodledge reinforcement assembly RH
19. Rear lower hoodledge RH
20. Battery tray
21. Rear lower hoodledge LH
22. Hoodledge LH
23. Hoodledge reinforcement assembly LH
24. Hoodledge reinforcement LH
25. Side dash LH
26. Second crossmember assembly (RH/LH)
27. Inner sill (RH/LH)
28. Front side member assembly (RH/LH)
29. Center floor member assembly
30. Rear side member rear (RH/LH)
31. Rear crossmember
32. Second seat mounting crossmember
33. Third seat mounting bracket assembly
34. Rope hook bracket
35. Rear floor side LH
36. Rear floor side upper extension assembly LH
37. Third seat mounting rear crossmember assembly
38. Trim mounting bracket
39. Rear floor side upper extension assembly RH
BRM-4
BODY REPAIR
< SERVICE INFORMATION >
BODY COMPONENT PARTS
A
B
C
D
E
F
G
H
I
J
BRM
L
M
N
O
LIIA1788E
P
1. Rear roof rail
2. Roof bow No 5
3. Roof 4th bow
4. Roof rack plate
BRM-5
BODY REPAIR
< SERVICE INFORMATION >
5. Roof 3rd bow
6. Roof bow second bracket
7. Roof 2nd bow
8. Roof 1st bow
9. Front roof rail
10. Roof
11. Sunroof reinforcement
12. Front inner pillar upper (RH, LH)
13. Dash upper crossmember assembly
14. Dash upper assembly
15. Hood assembly
16. Front fender (RH, LH)
17. Front pillar hinge brace (RH, LH)
18. Outer sill reinforcement (RH, LH)
19. Front body side outer (RH, LH)
20. Front door assembly (RH, LH)
21. Rear door assembly (RH, LH)
22. Rear body side outer (RH, LH)
23. Rear fender extension RH/LH
24. Body side outer assembly
25. Center pillar hinge brace
26. Center inner pillar (RH, LH)
27. Rear wheel housing inner (RH, LH)
28. Rear wheel housing outer (RH, LH)
29. Back pillar reinforcement (RH, LH)
30. Outer roof side rail reinforcement (RH/LH)
31. Rear inner side panel (RH, LH)
32. Body side inner reinforcement assembly (RH, LH)
33. Main back pillar (RH, LH)
34. Lift gate assembly
BRM-6
BODY REPAIR
< SERVICE INFORMATION >
FRAME COMPONENT PARTS
A
B
C
D
E
F
G
H
I
J
BRM
L
M
N
O
LIIA1789E
P
1. Frame assembly
2. 1st cab mounting bracket RH/LH
3. Front side member extension assembly RH/LH
4. 1st crossmember assembly
5. Front upper link mounting bracket RH/LH
BRM-7
BODY REPAIR
< SERVICE INFORMATION >
6. Front shock absorber mounting bracket RH/LH
7. Bound bumper bracket RH/LH
8. Front brake hose bracket RH/LH
9. Panhard rod bracket reinforcement
10. 4th crossmember gusset RH/LH
11. 2nd cab mounting bracket RH/LH
12. Crossmember support RH/LH
13. 3rd cab mounting bracket RH/LH
14. 4th cab mounting bracket RH/LH
15. Rear suspension mounting bracket RH/LH
16. Rear brake hose bracket
17. Rear bound bumper bracket RH/LH
18. Cab mounting bracket assembly RH/LH
19. 4th crossmember gusset RH/LH
20. Front differential mounting bracket RH/LH
21. 2nd crossmember assembly
22. 3rd crossmember assembly
23. 4th crossmember assembly
24. 5th crossmember assembly
25. 6th crossmember assembly
26. 9th crossmember assembly
Body Mounting INFOID:0000000001733164
