Image preview - the first page of the document
>> Download FSU documenatation <<
Text preview - extract from the document
SUSPENSION
A
SECTION
FRONT SUSPENSION
FSU B
C
D
FSU
CONTENTS
PRECAUTION .............................................. 2
. REMOVAL AND INSTALLATION .............. 13
. F
PRECAUTIONS .................................................. 2
. COIL SPRING AND SHOCK ABSORBER ....... 13
Precaution for Supplemental Restraint System Removal and Installation ........................................13
. G
(SRS) "AIR BAG" and "SEAT BELT PRE-TEN-
SIONER" .................................................................. 2
. STABILIZER BAR ............................................. 14
Precaution ................................................................ 2
. Removal and Installation ........................................14
.
H
PREPARATION ........................................... 3
. LOWER LINK .................................................... 15
Removal and Installation ........................................15
.
PREPARATION .................................................. 3
. I
Special Service Tool ................................................ 3
. UPPER LINK ..................................................... 16
Commercial Service Tool ......................................... 3
. Removal and Installation ........................................16
.
SYMPTOM DIAGNOSIS .............................. 4
. UPPER BALL JOINT AND LOWER BALL J
JOINT ................................................................ 17
NOISE, VIBRATION, AND HARSHNESS Removal and Installation ........................................17
.
(NVH) TROUBLESHOOTING ............................ 4
. K
NVH Troubleshooting Chart ..................................... 4
.
KNUCKLE ......................................................... 18
Removal and Installation ........................................18
.
ON-VEHICLE MAINTENANCE .................... 5
.
DISASSEMBLY AND ASSEMBLY ............. 21
. L
ON-VEHICLE SERVICE ..................................... 5
.
Front Suspension Parts ............................................ 5
.
COIL SPRING AND SHOCK ABSORBER ....... 21
Front Wheel Alignment ............................................. 5
. Disassembly and Assembly ....................................21
.
M
UPPER BALL JOINT AND LOWER BALL SERVICE DATA AND SPECIFICATIONS
JOINT ................................................................. 9
. (SDS) ........................................................... 23
.
Inspection ................................................................. 9
. N
SERVICE DATA AND SPECIFICATIONS
KNUCKLE .........................................................11
. (SDS) ................................................................. 23
On-Vehicle Inspection and Service ........................ 11
. General Specification (Front) ..................................23 .
O
Spring Free Height .................................................23 .
ON-VEHICLE REPAIR ................................ 12
. Wheel Alignment (Unladen*1) ................................23 .
Ball Joint .................................................................24
.
FRONT SUSPENSION ASSEMBLY .................12
. Wheelarch Height (Unladen*1) ...............................24 . P
Component ............................................................. 12
.
FSU-1
PRECAUTIONS
< PRECAUTION >
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER" INFOID:0000000001672899
The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
