Image preview - the first page of the document
>> Download PB documenatation <<
Text preview - extract from the document
BRAKES
A
SECTION
PARKING BRAKE SYSTEM
PB B
C
D
E
CONTENTS
PREPARATION ........................................... 2
. Removal and Installation ......................................... 4
. PB
PREPARATION .................................................. 2
. PARKING BRAKE SHOE .................................. 6
Commercial Service Tool ......................................... 2
. Removal and Installation ......................................... 6
.
G
ON-VEHICLE REPAIR ................................. 3
. SERVICE DATA AND SPECIFICATIONS
(SDS) ............................................................ 9
.
PARKING BRAKE SYSTEM .............................. 3
. H
On-Vehicle Service .................................................. 3
. SERVICE DATA AND SPECIFICATIONS
(SDS) .................................................................. 9
REMOVAL AND INSTALLATION ............... 4
. Parking Drum Brake ................................................ 9
. I
Parking Brake Control ............................................. 9
.
PARKING BRAKE CONTROL ........................... 4
.
Component ............................................................... 4
.
J
K
L
M
N
O
P
PB-1
PREPARATION
< PREPARATION >
PREPARATION
PREPARATION
Commercial Service Tool INFOID:0000000001297773
Tool number Description
(Kent-Moore No.)
Tool name
-- Measuring rear rotor drum to parking
(J-21177-A) brake shoe clearance
Brake drum clearance gauge
WFIA0167E
Power tool Loosening bolts and nuts
PBIC0190E
PB-2
PARKING BRAKE SYSTEM
< ON-VEHICLE REPAIR >
ON-VEHICLE REPAIR A
PARKING BRAKE SYSTEM
On-Vehicle Service INFOID:0000000001297776
B
PEDAL STROKE
