Image preview - the first page of the document
RSU


>> Download RSU documenatation <<

Text preview - extract from the document
SUSPENSION

                                                                                                                                                                      A




                                                                                   SECTION
                                                                                                REAR SUSPENSION
                                                                                                               RSU                                                    B



                                                                                                                                                                      C


                                                                                                                                                                      D


                                                                                                                                                                      RSU
                                                                  CONTENTS
PRECAUTION .............................................. 2
                                                     .                               Component .............................................................. 9
                                                                                                                                                        .             F

PRECAUTIONS .................................................. 2
                                                         .                         REMOVAL AND INSTALLATION .............. 10
                                                                                                                       .
  Precaution for Supplemental Restraint System                                                                                                                        G
  (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                          REAR SUSPENSION MEMBER ....................... 10
  SIONER" .................................................................. 2
                                                                      .              Removal and Installation ........................................10
                                                                                                                                                  .
  Precaution for Rear Suspension .............................. 2     .            SHOCK ABSORBER ........................................ 14                         H
PREPARATION ........................................... 3
                                                   .                                 Removal and Installation ........................................14
                                                                                                                                                  .

PREPARATION .................................................. 3
                                                         .                         SUSPENSION ARM .......................................... 15
                                                                                     Removal and Installation ........................................15
                                                                                                                                                  .                    I
  Commercial Service Tool ......................................... 3
                                                             .
                                                                                   FRONT LOWER LINK ....................................... 17
SYMPTOM DIAGNOSIS .............................. 4
                                            .
                                                                                     Removal and Installation ........................................17
                                                                                                                                                  .                   J
NOISE, VIBRATION, AND HARSHNESS
                                                                                   REAR LOWER LINK & COIL SPRING ............. 19
(NVH) TROUBLESHOOTING ............................ 4
                                             .                                       Removal and Installation ........................................19
                                                                                                                                                  .
  NVH Troubleshooting Chart ..................................... 4
                                                           .                                                                                                          K
                                                                                   STABILIZER BAR ............................................. 21
ON-VEHICLE MAINTENANCE .................... 5
                                       .                                             Removal and Installation ........................................21
                                                                                                                                                  .
REAR SUSPENSION ASSEMBLY .................... 5
                                        .                                          SERVICE DATA AND SPECIFICATIONS                                                    L
  On-Vehicle Inspection .............................................. 5
                                                                .
  Wheel Alignment Inspection ..................................... 5
                                                                .
                                                                                   (SDS) ........................................................... 22
                                                                                                                                                 .

SHOCK ABSORBER ......................................... 8
                                                   .                               SERVICE DATA AND SPECIFICATIONS                                                    M
  Inspection ................................................................. 8
                                                                        .          (SDS) ................................................................. 22
                                                                                     Wheel Alignment ....................................................22  .
ON-VEHICLE REPAIR ................................. 9
                                               .                                     Ball Joint .................................................................22
                                                                                                                                                             .        N
                                                                                     Wheelarch Height (Unladen*) .................................23         .
REAR SUSPENSION ASSEMBLY .................... 9
                                        .
                                                                                                                                                                      O



                                                                                                                                                                      P




                                                                            RSU-1
                                              PRECAUTIONS
< PRECAUTION >
PRECAUTION
PRECAUTIONS
Precaution for Supplemental Restraint System (SRS) "AIR BAG" and "SEAT BELT
PRE-TENSIONER"                                                                                       INFOID:0000000001675459



The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the SR and SB section of this Service Man-
ual.
WARNING:
