Image preview - the first page of the document
SE


>> Download SE documenatation <<

Text preview - extract from the document
BODY INTERIOR

                                                                                                                                                              A




                                                                                                   SECTION                   SE            SEAT
                                                                                                                                                              B



                                                                                                                                                              C


                                                                                                                                                              D


                                                                                                                                                              E
                                                                 CONTENTS
SERVICE INFORMATION ........................... 2
                                           .                                     PREPARATION .......................................... 24
                                                                                                                                    .                         F

SQUEAK AND RATTLE TROUBLE DIAG-                                                  PREPARATION ................................................. 24
NOSES ............................................................... 2
                                                                .                  Special Service Tool ...............................................24
                                                                                                                                                   .          G
  Work Flow ................................................................ 2
                                                                      .            Commercial Service Tool .......................................24
                                                                                                                                                   .
  Generic Squeak and Rattle Troubleshooting ........... 4             .
  Diagnostic Worksheet .............................................. 6
                                                                      .          ON-VEHICLE REPAIR ................................ 25
                                                                                                                                .
                                                                                                                                                              H
COMPONENT DIAGNOSIS ......................... 8
                                         .                                       FRONT SEAT .................................................... 25
                                                                                   Exploded View ........................................................25
                                                                                                                                                     .
POWER SEAT .................................................... 8
                                                          .                        Removal and Installation ........................................30
                                                                                                                                                     .         I
  Wiring Diagram -- Driver Side -- ............................ 8
                                                         .
  Wiring Diagram -- Passenger Side -- ................... 12
                                                         .                       REAR SEAT ...................................................... 31
                                                                                   Removal and Installation ........................................31
                                                                                                                                                .
HEATED SEAT ..................................................15
                                                          .                                                                                                   SE
  Description ............................................................. 15
                                                                       .         DISASSEMBLY AND ASSEMBLY ............. 33
                                                                                                                    .
  Wiring Diagram ...................................................... 16
                                                                       .
                                                                                 FRONT SEAT .................................................... 33
                                                                                   Exploded View ........................................................33
                                                                                                                                                     .        K
PRECAUTION ............................................. 22
                                                     .
                                                                                   Seatback Assembly ................................................38
                                                                                                                                                     .
PRECAUTIONS .................................................22
                                                         .                         Seat Cushion Trim and Pad ...................................40   .
  Precaution for Supplemental Restraint System                                                                                                                L
  (SRS) "AIR BAG" and "SEAT BELT PRE-TEN-                                        REAR SEAT ...................................................... 43
  SIONER" ................................................................ 22
                                                                      .            Exploded View ........................................................43
                                                                                                                                                     .
  Precaution for Work ............................................... 22
                                                                      .            Disassembly and Assembly ....................................43   .
                                                                                                                                                              M
  Precaution Necessary for Steering Wheel Rota-
  tion After Battery Disconnect .................................. 22 .
                                                                                                                                                              N



                                                                                                                                                              O



                                                                                                                                                              P




Revision: October 2008                                                      SE-1                                                       2009 Pathfinder
                         SQUEAK AND RATTLE TROUBLE DIAGNOSES
< SERVICE INFORMATION >
SERVICE INFORMATION
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Work Flow                                                                                            INFOID:0000000003935850




                                                                                                   SBT842




CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any
customer's comments; refer to SE-6, "Diagnostic Worksheet". This information is necessary to duplicate the
conditions that exist when the noise occurs.
