Image preview - the first page of the document
el


>> Download el documenatation <<

Text preview - extract from the document


                                                                                               ELECTRICAL SYSTEM



MODIFICATION NOTICE:
                                                                                                SECTION                   EL
Wiring diagrams have been changed.




                                                                 CONTENTS
PRECAUTIONS ................................................... 2003           REAR FOG LAMP ............................................... 2036
  Supplemental Restraint System (SRS) ``AIR                                       Wiring Diagram - R/FOG -/LHD Models.......... 2036
  BAG'' and ``SEAT BELT PRE-TENSIONER'' .. 2003                                   Wiring Diagram - R/FOG -/RHD Models ......... 2037
POWER SUPPLY ROUTING............................... 2004                       TURN SIGNAL AND HAZARD WARNING
  Schematic ........................................................ 2004      LAMPS ................................................................. 2038
  Wiring Diagram - POWER -............................. 2005                      Wiring Diagram - TURN -/Type-1 .................... 2038
STARTING SYSTEM ........................................... 2012                  Wiring Diagram - TURN -/Type-2 .................... 2040
  Wiring Diagram - START -/M/T Models .......... 2012                          ILLUMINATION.................................................... 2043
CHARGING SYSTEM .......................................... 2013                   Wiring Diagram - ILL -/LHD Models ................ 2043
  Wiring Diagram - CHARGE -/Gasoline                                              Wiring Diagram - ILL -/RHD Models................ 2045
  Engine .............................................................. 2013   INTERIOR ROOM LAMP..................................... 2047
  Wiring Diagram - CHARGE -/Diesel Engine ... 2014                                Wiring Diagram - ROOM/L - ............................ 2047
  Construction ..................................................... 2015      SPOT LAMP ........................................................ 2048
  Service Data and Specifications (SDS)........... 2016                           Wiring Diagram - INT/L - ................................. 2048
COMBINATION SWITCH .................................... 2017                   METER AND GAUGES ....................................... 2049
  Check ............................................................... 2017      Combination Meter........................................... 2049
HEADLAMP - Conventional Type -................... 2018                            Wiring Diagram - METER -/Gasoline Engine
  Wiring Diagram - H/LAMP -/LHD Models........ 2018                               with Tachometer .............................................. 2052
  Wiring Diagram - H/LAMP -/RHD Models ....... 2020                               Wiring Diagram - METER -/Diesel Engine with
HEADLAMP - Daytime Light System - ............. 2022                              Tachometer ...................................................... 2054
  Wiring Diagram - DTRL -................................. 2022                   Wiring Diagram - METER -/Gasoline Engine
HEADLAMP - Dim-dip Lamp System - ............. 2025                               without Tachometer ......................................... 2056
  Wiring Diagram - DIMDIP -.............................. 2025                    Wiring Diagram - METER -/Diesel Engine
HEADLAMP - Headlamp Aiming Control -....... 2028                                  without Tachometer ......................................... 2057
  Wiring Diagram - H/AIM - ................................ 2028                  Unified Control Meter System Description ...... 2058
PARKING, LICENSE AND TAIL LAMPS ........... 2030                                  Meter/gauge Operation and Odo/Trip Meter
  Wiring Diagram - TAIL/L -/Except LHD                                            Segment Check in Diagnosis Mode ................ 2058                       EL
  Models.............................................................. 2030       Flexible Print Circuit (FPC) (Models with
  Wiring Diagram - TAIL/L -/LHD Models........... 2032                            Tachometer)..................................................... 2059
STOP LAMP ........................................................ 2034           Trouble Diagnoses/Models with Tachometer .. 2060
  Wiring Diagram - STOP/L - ............................. 2034                    Trouble Diagnoses/Models without
BACK-UP LAMP.................................................. 2035               Tachometer ...................................................... 2065
  Wiring Diagram - BACK/L -/M/T Models ......... 2035                             Electrical Components Inspection ................... 2070
WARNING LAMPS .............................................. 2072                                         Wiring Diagram - WINDOW -/Without
  Schematic ........................................................ 2072                                 Interruption Detection Function........................ 2109
  Wiring Diagram - WARN -/Gasoline Engine.... 2073                                                        Trouble Diagnoses/Without Interruption
  Wiring Diagram - WARN -/Diesel Engine........ 2078                                                      Detection Function ........................................... 2113
  Electrical Components Inspection ................... 2083                                               System Description/With Interruption Detection
  Wiring Diagram - CHIME -/LHD Models.......... 2084                                                      Function ........................................................... 2114
  Wiring Diagram - CHIME -/RHD Models ......... 2085                                                      Schematic/With Interruption Detection
FRONT WIPER AND WASHER .......................... 2086                                                    Function ........................................................... 2115
  Wiring Diagram - WIPER -/LHD Models with                                                                Wiring Diagram - WINDOW -/With Interruption
  Intermittent ....................................................... 2086                               Detection Function ........................................... 2116
  Wiring Diagram - WIPER -/LHD Models                                                                     Trouble Diagnoses/With Interruption Detection
  without Intermittent........................................... 2087                                    Function ........................................................... 2120
  Wiring Diagram - WIPER -/RHD M/T Models                                                               POWER DOOR LOCK......................................... 2122
  with Intermittent................................................ 2088                                  System Description .......................................... 2122
  Wiring Diagram - WIPER -/RHD Models                                                                     Wiring Diagram - D/LOCK -............................. 2123
  without Intermittent........................................... 2090                                    Trouble Diagnosis ............................................ 2125
HEADLAMP WASHER ........................................ 2092                                           MULTI-REMOTE CONTROL SYSTEM ............... 2129
  Wiring Diagram - HLC - ................................... 2092                                         System Description .......................................... 2129
HORN ................................................................... 2093                             Schematic ........................................................ 2130
  Wiring Diagram - HORN -................................ 2093                                            Wiring Diagram - MULTI - ............................... 2131
CIGARETTE LIGHTER........................................ 2094                                            Trouble Diagnoses........................................... 2135
  Wiring Diagram - CIGAR -............................... 2094                                            ID Code Entry Procedure ................................ 2139
CLOCK................................................................. 2095                             NATS (Nissan Anti-Theft System)/Models with
  Wiring Diagram - CLOCK -.............................. 2095                                           KA24E .................................................................. 2140
REAR WINDOW DEFOGGER AND MIRROR                                                                           Wiring Diagram - NATS -................................. 2140
DEFOGGER ......................................................... 2096                                 NATS (Nissan Anti-Theft System)/Diesel
  Wiring Diagram - DEF -/LHD Models .............. 2096                                                 engine .................................................................. 2141
  Wiring Diagram - DEF -/RHD Models ............. 2097                                                    Wiring Diagram - NATS -/LHD Models............ 2141
  Electrical Components Inspection ................... 2098                                               Wiring Diagram - NATS -/RHD Models ........... 2142
AUDIO .................................................................. 2099                           LOCATION OF ELECTRICAL UNITS................. 2143
  Wiring Diagram - AUDIO -/LHD Models                                                                     Engine Compartment ....................................... 2143
  Type-2 .............................................................. 2099                              Passenger Compartment ................................. 2144
  Wiring Diagram - AUDIO -/LHD Models                                                                   HARNESS LAYOUT ............................................ 2146
  Type-3 .............................................................. 2100                              Main Harness................................................... 2146
  Wiring Diagram - AUDIO -/RHD Models ......... 2102                                                      Engine Room Harness..................................... 2152
AUDIO ANTENNA ............................................... 2103                                        Engine Control Harness................................... 2160
  Power Antenna/Wiring Diagram - P/ANT -...... 2103                                                       Alternator Harness ........................................... 2164
POWER DOOR MIRROR .................................... 2104                                               Instrument Harness.......................................... 2165
  Wiring Diagram - MIRROR -/LHD Models....... 2104                                                        Room Lamp Harness/LHD Models.................. 2166
  Wiring Diagram - MIRROR -/RHD Models ...... 2105                                                        Room Lamp Harness/RHD Models ................. 2167
HEATED SEAT .................................................... 2106                                     Chassis Harness and Tail Harness ................. 2168
  Wiring Diagram - H/SEAT - ............................. 2106                                            Front Door Harness (LH side) ......................... 2169
POWER WINDOW ............................................... 2108                                         Front Door Harness (RH side)......................... 2170
  Schematic/Without Interruption Detection                                                              WIRING DIAGRAM CODES (CELL CODES)..... 2171
  Function ........................................................... 2108

                                                                   WIRING DIAGRAM REFERENCE CHART

                           COOLING FAN ..........................................................................................................     LC   SECTION
                           ECCS, IGNITION SYSTEM, QUICK-GLOW SYSTEM, FUEL HEATER SYSTEM ..                                                            EC   SECTION
                           ANTI-LOCK BRAKE SYSTEM ..................................................................................                  BR   SECTION
                           SRS ``AIR BAG'' ........................................................................................................   RS   SECTION
                           HEATER AND AIR CONDITIONER ..........................................................................                      HA   SECTION




                                                                                      EL-2002
                                            PRECAUTIONS

                                            Supplemental Restraint System (SRS) ``AIR
                                            BAG'' and ``SEAT BELT PRE-TENSIONER''
The Supplemental Restraint System such as ``AIR BAG'' and ``SEAT BELT PRE-TENSIONER'' used along
with a seat belt, helps to reduce the risk or severity of injury to the driver and front passenger in a frontal
collision. The SRS system composition which is available to NISSAN MODEL D22 is as follows (The com-
position varies according to the destination and optional equipment.):
Driver air bag module (located in the center of the steering wheel), front passenger air bag module (located
on the instrument panel on passenger side), seat belt pre-tensioner, a diagnosis sensor unit, warning lamp,
wiring harness and spiral cable.
Information necessary to service the system safely is included in the RS section of this Service Manual.
WARNING:
q To avoid rendering the SRS inoperative, which could increase the risk of personal injury or death
     in the event of a collision which would result in air bag inflation, all maintenance must be per-
     formed by an authorized NISSAN dealer.
q Improper maintenance, including incorrect removal and installation of the SRS, can lead to per-
     sonal injury caused by unintentional activation of the system. For removal of Spiral Cable and
     Air Bag Module, see the RS section.
q Do not use electrical test equipment on any circuit related to the SRS unless instructed to in this
     Service Manual. Spiral Cable and wiring harnesses (except ``SEAT BELT PRE-TENSIONER'')
     covered with yellow insulation either just before the harness connectors or for the complete har-
     ness are related to the SRS.




                                                 EL-2003
POWER SUPPLY ROUTING

    Schematic




                       HEL669A


       EL-2004
                       POWER SUPPLY ROUTING

                             Wiring Diagram -- POWER --
BATTERY POWER SUPPLY -- IGNITION SWITCH IN ANY POSITION




                                                          HEL670A

                                EL-2005
POWER SUPPLY ROUTING
    Wiring Diagram -- POWER -- (Cont'd)




                                          HEL671A

        EL-2006
POWER SUPPLY ROUTING
    Wiring Diagram -- POWER -- (Cont'd)




                                          HEL672A

        EL-2007
                        POWER SUPPLY ROUTING
                            Wiring Diagram -- POWER -- (Cont'd)
ACCESSORY POWER SUPPLY -- IGNITION SW. IN ``ACC'' OR ``ON''




                                                                  HEL673A

                                  EL-2008
                         POWER SUPPLY ROUTING
                             Wiring Diagram -- POWER -- (Cont'd)
IGNITION POWER SUPPLY -- IGNITION SW. IN ``ON'' AND/OR ``START''




                                                                   HEL674A

                                   EL-2009
POWER SUPPLY ROUTING
    Wiring Diagram -- POWER -- (Cont'd)




                                          HEL675A

        EL-2010
POWER SUPPLY ROUTING
    Wiring Diagram -- POWER -- (Cont'd)




                                          HEL676A

        EL-2011
STARTING SYSTEM

 Wiring Diagram -- START --/M/T Models




                                     HEL677A


    EL-2012
CHARGING SYSTEM

  Wiring Diagram -- CHARGE --/Gasoline
  Engine




                                         HEL680A

     EL-2013
CHARGING SYSTEM

  Wiring Diagram -- CHARGE --/Diesel Engine




                                      HEL681A


     EL-2014
CHARGING SYSTEM

  Construction




                  MEL383IA




     EL-2015
                                                CHARGING SYSTEM

                                                     Service Data and Specifications (SDS)

ALTERNATOR
                                                    LR170-765                                           LR160-728F
Type
                                                                              HITACHI

Applied model                                         KA24                                                TD25

Nominal rating                   V-A                  12-70                                               12-60

Ground polarity                                                               Negative

Minimum revolution under no-
load                                                                      Less than 1,000
(When 13.5V is applied)      rpm

                                                    More than                                           More than
                                                    17/1,300                                            17/1,300
Hot output current                                  More than                                           More than
(When 13.5V is applied)         A/rpm               54/2,500                                            48/2,500
                                                    More than                                           More than
                                                    75/5,000                                            57/5,000

Regulated output voltage           V                                         14.1 - 14.7

Minimum length of brush
                                                                             6.0 (0.236)
                           mm (in)

Brush spring pressure
                                                                 1.0 - 3.43 (102 - 350, 3.60 - 12.34)
                          N (g, oz)

Slip ring minimum outer diameter
                                                                            26.0 (1.024)
                          mm (in)

Rotor (Field coil) resistance                                                   2.58

*: Models with power steering and air conditioner




                                                              EL-2016
             COMBINATION SWITCH

                Check
LHD MODELS




                                  HEL682A

                  EL-2017
HEADLAMP -- Conventional Type --

         Wiring Diagram -- H/LAMP --/LHD Models




                                             HEL898


            EL-2018
HEADLAMP -- Conventional Type --
       Wiring Diagram -- H/LAMP --/LHD Models
       (Cont'd)




                                           HEL684A


            EL-2019
HEADLAMP -- Conventional Type --

         Wiring Diagram -- H/LAMP --/RHD Models




                                             HEL685A

            EL-2020
HEADLAMP -- Conventional Type --
       Wiring Diagram -- H/LAMP --/RHD Models
       (Cont'd)




                                          HEL686A


            EL-2021
HEADLAMP -- Daytime Light System --

           Wiring Diagram -- DTRL --




                                       HEL687A


              EL-2022
HEADLAMP -- Daytime Light System --
         Wiring Diagram -- DTRL -- (Cont'd)




                                              HEL688A

              EL-2023
HEADLAMP -- Daytime Light System --
         Wiring Diagram -- DTRL -- (Cont'd)




                                              HEL689A

              EL-2024
HEADLAMP -- Dim-dip Lamp System --

          Wiring Diagram -- DIMDIP --




                                        HEL690A


             EL-2025
HEADLAMP -- Dim-dip Lamp System --
         Wiring Diagram -- DIMDIP -- (Cont'd)




                                                HEL691A

              EL-2026
HEADLAMP -- Dim-dip Lamp System --
         Wiring Diagram -- DIMDIP -- (Cont'd)




                                                HEL329A

              EL-2027
HEADLAMP -- Headlamp Aiming Control --

            Wiring Diagram -- H/AIM --




                                         HEL692A


               EL-2028
HEADLAMP -- Headlamp Aiming Control --
           Wiring Diagram -- H/AIM -- (Cont'd)




                                                 HEL693A

                EL-2029
PARKING, LICENSE AND TAIL LAMPS

         Wiring Diagram -- TAIL/L --/Except LHD
         Models




                                              HEL694A

            EL-2030
PARKING, LICENSE AND TAIL LAMPS
          Wiring Diagram -- TAIL/L --/Except LHD
          Models (Cont'd)




                                               HEL695A


             EL-2031
PARKING, LICENSE AND TAIL LAMPS

         Wiring Diagram -- TAIL/L --/LHD Models




                                              HEL696A




            EL-2032
PARKING, LICENSE AND TAIL LAMPS
          Wiring Diagram -- TAIL/L --/LHD Models
          (Cont'd)




                                               HEL697A


             EL-2033
 STOP LAMP

Wiring Diagram -- STOP/L --




                              HEL698A


   EL-2034
BACK-UP LAMP

Wiring Diagram -- BACK/L --/M/T Models




                                    HEL699A


   EL-2035
REAR FOG LAMP

 Wiring Diagram -- R/FOG --/LHD Models




                                     HEL701A



    EL-2036
REAR FOG LAMP

 Wiring Diagram -- R/FOG --/RHD Models




                                     HEL702A


    EL-2037
              TURN SIGNAL AND HAZARD WARNING LAMPS

                          Wiring Diagram -- TURN --/Type-1
FOR EUROPE (Single cab)




                                                             HEL703A



                             EL-2038
TURN SIGNAL AND HAZARD WARNING LAMPS
             Wiring Diagram -- TURN --/Type-1 (Cont'd)




                                                  HEL704A


                 EL-2039
              TURN SIGNAL AND HAZARD WARNING LAMPS

                               Wiring Diagram -- TURN --/Type-2
FOR EUROPE (King cab and Double cab)




                                                                  HEL705A



                                   EL-2040
TURN SIGNAL AND HAZARD WARNING LAMPS
             Wiring Diagram -- TURN --/Type-2 (Cont'd)




                                                  HEL706A

                 EL-2041
TURN SIGNAL AND HAZARD WARNING LAMPS
             Wiring Diagram -- TURN --/Type-2 (Cont'd)




                                                  HEL707A

                 EL-2042
ILLUMINATION

Wiring Diagram -- ILL --/LHD Models




                                      HEL708A


   EL-2043
ILLUMINATION
Wiring Diagram -- ILL --/LHD Models
(Cont'd)




                                      HEL709A

   EL-2044
ILLUMINATION

Wiring Diagram -- ILL --/RHD Models




                                      HEL710A


   EL-2045
ILLUMINATION
Wiring Diagram -- ILL --/RHD Models
(Cont'd)




                                      HEL711A

   EL-2046
INTERIOR ROOM LAMP

   Wiring Diagram -- ROOM/L --




                                 HEL712A


      EL-2047
 SPOT LAMP

Wiring Diagram -- INT/L --




                             HEL713A


   EL-2048
                  METER AND GAUGES

                    Combination Meter
WITH TACHOMETER




                                        HEL714A

                       EL-2049
                     METER AND GAUGES
                        Combination Meter (Cont'd)
WITHOUT TACHOMETER




                                                     HEL715A

                           EL-2050
                           METER AND GAUGES
                              Combination Meter (Cont'd)
CONSTRUCTION (Without tachometer)




                                                           SEL434W




                                    EL-2051
METER AND GAUGES

  Wiring Diagram -- METER --/Gasoline
  Engine with Tachometer




                                        HEL716A

     EL-2052
METER AND GAUGES
   Wiring Diagram -- METER --/Gasoline
   Engine with Tachometer (Cont'd)




                                         HEL717A

      EL-2053
METER AND GAUGES

  Wiring Diagram -- METER --/Diesel Engine
  with Tachometer




                                       HEL718A

     EL-2054
METER AND GAUGES
   Wiring Diagram -- METER --/Diesel Engine
   with Tachometer (Cont'd)




                                        HEL719A

      EL-2055
METER AND GAUGES

  Wiring Diagram -- METER --/Gasoline
  Engine without Tachometer




                                        HEL720A

     EL-2056
METER AND GAUGES

  Wiring Diagram -- METER --/Diesel Engine
  without Tachometer




                                       HEL721A

     EL-2057
       METER AND GAUGES

           Unified Control Meter System Description
           UNIFIED CONTROL METER
           Speedometer, odo/trip meter, tachometer, fuel gauge and water
           temperature gauge are controlled totally by unified meter control
           unit.




           Meter/gauge Operation and Odo/Trip Meter
           Segment Check in Diagnosis Mode
           DIAGNOSIS FUNCTION
           q   Odo/trip meter segment can be checked in diagnosis mode.
           q   Meters/gauges can be checked in diagnosis mode.




           HOW TO ALTERNATE DIAGNOSIS MODE
           1. Turn ignition switch to ON and change odo/trip meter to
              ``TRIP A'' or ``TRIP B''.
           2. Turn ignition switch to OFF.
           3. Turn ignition switch to ON when pushing odo/trip meter
              switch.
           4. Confirm that trip meter indicates ``000.0''.
           5. Push odo/trip meter switch more than three times within 5
              seconds.
           6. All odo/trip meter segments should be turned on.
 SEL110V   NOTE: If some segments are not turned on, unified meter
                   control unit should be replaced.
              At this point, the unified control meter is turned to diagnosis
              mode.




           7. Push odo/trip meter switch. Indication of each meter/gauge
              should be as shown left during pushing odo/trip meter switch
              if it is no malfunctioning.
           NOTE: It takes about 1 minute for indication of fuel gauge
                     to become stable.




SEL111VA


               EL-2058
      METER AND GAUGES
         Meter/gauge Operation and Odo/Trip Meter
         Segment Check in Diagnosis Mode (Cont'd)




SEL427W

          Flexible Print Circuit (FPC) (Models with
          Tachometer)
          Tachometer, fuel gauge and water temperature gauge are con-
          nected with unified meter control unit (speedometer) by Flexible
          Print Circuit (FPC) connector. When replace or remove and
          install unified control unit (speedometer), disconnect and con-
          nect FPC connector according to the following steps.




          DISCONNECT
          1. Open connector cover.
          2. Release connector lock by holding both ends of it and pull-
             ing it up.
          3. Disconnect FPC by pulling it up.




SEL109V

          CONNECT
          1. Insert FPC into connector and lock connector pushing FPC
             downward.
          2. Check secure connection of FPC.
          3. Check continuity of check land terminals for secure connec-
             tion of FPC.
               Resistance: 0
          4. Close connector cover.


SEL162V




              EL-2059
                                              METER AND GAUGES

                                                       Trouble Diagnoses/Models with Tachometer
PRELIMINARY CHECK
       CHECK-IN


           .
 Can Diagnosis mode         No       Do meter warning           Yes       Check the screws              Can Diagnosis mode
                                 c                                    c                             c
 be activated? Refer to              lamps operate?                       securing speedometer          be activated?
 ``Meter/Gauge Opera-                                                     and FPC.                        m Yes
                                                  No                                                                       No
 tion and Odo/Trip Meter                                                  (The screws are
 Segment Check in                                                         located behind the
 Diagnosis Mode'',                                                        combination meter. For
 EL-2058.                                                                 details refer to
                                                                          EL-2070.)
               Yes
                                              .
                                     Check power supply
                                     and ground circuit.
                                     Refer to ``POWER
                                     SUPPLY AND
                                     GROUND CIRCUIT
                                     CHECK'', EL-2062.

           .
 Check meter/gauge
                            b
 operation in Diagnosis
 mode.




           .                                                                        .                                  .
 Malfunction is indicated                                                 No malfunction is indi-       Replace speedometer
 in Diagnosis mode.                                                       cated in Diagnosis            (unified meter control
                                                                          mode.                         unit).


           .                                                                        .
 Check the following:                                                     SYMPTOM CHART 2
 q FPC connector con-
                            NG                                            Refer to EL-2061.
   nection
   Refer to ``Flexible
   Print Circuit (FPC)'',
   EL-2059.
 q Screws securing the
   malfunctioning meter/
   gauge
   (The screws are
   located behind the
   combination meter.
   For details refer to
   EL-2070.)

               OK
           .                                                .
 SYMPTOM CHART 1                     Reconnect FPC connector and check continuity between
 Refer to EL-2061.                   check land terminals and/or repair malfunctioning part.
                                     Refer to ``Flexible Print Circuit (FPC)'', EL-2059.




                                                           EL-2060
                                                    METER AND GAUGES
                                                       Trouble Diagnoses/Models with Tachometer
                                                       (Cont'd)
Before starting trouble diagnoses below, perform PRELIMINARY CHECK, EL-2060.

SYMPTOM CHART 1 (MALFUNCTION IS INDICATED IN DIAGNOSIS MODE)
          Symptom                                Possible causes                                         Repair order

Speedometer and/or odo/trip     q   Speedometer (Unified meter control unit)   q   Replace speedometer (unified meter control unit).
meter indicate(s) malfunction
in Diagnosis mode.

Multiple meter/gauge indicate
malfunction in Diagnosis
mode.

One of tachometer/fuel gauge/   q   Meter/Gauge                                1. Check resistance of meter/gauge indicating malfunction. If
water temp. gauge indicates     q   Speedometer (Unified meter control unit)      the resistance is NG, replace the meter/gauge. Refer to
malfunction in Diagnosis                                                          ``METER/GAUGE RESISTANCE CHECK'', EL-2070.
mode.                                                                          2. If the resistance is OK, replace speedometer (unified meter
                                                                                  control unit).


SYMPTOM CHART 2 (NO MALFUNCTION IS INDICATED IN DIAGNOSIS MODE)
          Symptom                                Possible causes                                         Repair order

Speedometer and odo/trip        1. Sensor                                      1. Check vehicle speed sensor.
meter are malfunctioning.          - Speedometer, Odo/Trip meter                  INSPECTION/VEHICLE SPEED SENSOR (Refer to
                                2. FPC connector                                  EL-2063.)
                                                                               2. Check FPC connector. Refer to ``FLEXIBLE PRINT CIRCUIT
                                3. Speedometer (Unified meter control unit)       (FPC)'', EL-2059.
                                                                               3. Replace speedometer (unified meter control unit).

Multiple meter/gauge are mal-   1. FPC connector                               1. Check FPC connector. Refer to ``FLEXIBLE PRINT CIRCUIT
functioning. (except                                                              (FPC)'', EL-2059.
speedometer, odo/trip meter)    2. Speedometer (Unified meter control unit)    2. Replace speedometer (unified meter control unit).

One of tachometer/fuel gauge/   1. Sensor/Engine revolution signal             1. Check the sensor for malfunctioning meter/gauge.
water temp. gauge is malfunc-      - Tachometer                                   INSPECTION/ENGINE REVOLUTION SIGNAL (Refer to
tioning.                                                                          EL-2063.)
                                   - Fuel gauge                                   INSPECTION/FUEL TANK GAUGE (Refer to EL-102.)
                                   - Water temp. gauge                            INSPECTION/THERMAL TRANSMITTER (Refer to
                                2. FPC connector                                  EL-2064.)
                                                                               2. Check FPC connector. Refer to ``Flexible Print Circuit
                                3. Speedometer (Unified meter control unit)       (FPC)'', EL-2059.
                                                                               3. Replace speedometer (unified meter control unit).




                                                                   EL-2061
      METER AND GAUGES
         Trouble Diagnoses/Models with Tachometer
         (Cont'd)
          POWER SUPPLY AND GROUND CIRCUIT CHECK
          Power supply circuit check
                   Terminals                  Ignition switch position
                               @     OFF               ACC                ON
                                    Battery           Battery            Battery
              2
              V            Ground
                                    voltage           voltage            voltage
                                                                         Battery
SEL420W       37
              V            Ground     0V                0V
                                                                         voltage

          If NG, check the following.
          q 7.5A fuse [No. 3 , located in fuse block (J/B)]
          q 10A fuse [No. 20 , located in fuse block (J/B)]
          q Harness for open or short between fuse and combination
              meter




          Ground circuit check
                      Terminals                         Continuity
                     3
                     V   - Ground                            Yes




SEL421W




              EL-2062
      METER AND GAUGES
         Trouble Diagnoses/Models with Tachometer
         (Cont'd)
           INSPECTION/VEHICLE SPEED SENSOR

          CHECK VEHICLE SPEED SENSOR                      OK       Vehicle speed sensor is
                                                               c
          OUTPUT.                                                  OK.
          1. Remove vehicle speed sensor from
             transmission.
          2. Check voltage between combination
             meter terminals V and V while
                               7      15
             quickly turning speed sensor pinion.
             Voltage: Approx. 0.5V

                                   NG

                               .
          CHECK VEHICLE SPEED SENSOR.                     NG       Replace vehicle speed
                                                               c
          Check resistance between vehicle speed                   sensor.
          sensor terminals V and V .
                           1      2
          Resistance: Approx. 250

                                   OK
                               .
SEL422W   Check harness or connector between
          speedometer and vehicle speed sensor.




SEL118V

           INSPECTION/ENGINE REVOLUTION SIGNAL (Models
           with tachometer)
                                              Terminals
             Engine        Check item                                   Explanation
                                                      @
          ECM con-
                           DC voltage
          trolled engine                                       Higher rpm = Higher voltage
                                                               Lower rpm = Lower voltage
          Carburetor                         16
                                             V       3
                                                     V         Voltage should change with
          Diesel TD27      AC voltage                          rpm.
SEL423W
          and QD32


           If NG, check the following.
             Engine                                  Check item
          ECM con-
                           q   Harness for open or short and connection
          trolled engine
                           q   Harness for open or short and connection
          Carburetor
                           q   Resistor etc.
          Diesel TD27      q   Harness for open or short and connection
          and QD32         q   Engine revolution sensor etc.




                 EL-2063
      METER AND GAUGES
         Trouble Diagnoses/Models with Tachometer
         (Cont'd)
           INSPECTION/FUEL LEVEL SENSOR

          CHECK GROUND CIRCUIT FOR FUEL              NG       Repair harness or connec-
                                                          c
          LEVEL SENSOR UNIT.                                  tor.
          Check harness continuity between fuel
          level sensor unit terminal V and ground.
                                     1
          Continuity should exist.

                                OK
SEL424W                     .
          CHECK FUEL LEVEL SENSOR UNITS.             NG       Repair or replace.
                                                          c
          Refer to ``FUEL LEVEL SENSOR UNIT                   Refer to FE section.
          CHECK'' (EL-2070).

                                OK

                            .
          CHECK HARNESS.                             NG       Repair harness or connec-
                                                          c
          1. Disconnect combination meter connec-             tor.
             tor N4 and fuel level sensor unit
             connector.
SEL425W
          2. Check harness continuity between
             combination meter terminal V and
                                           6
             fuel level sensor unit terminal V .
                                             3
          Continuity should exist.
          3. Check continuity between combination
             meter terminal V and ground.
                              6
          Continuity should not exist.

                                OK
                            .
          Fuel level sensor is OK.




           INSPECTION/THERMAL TRANSMITTER
          CHECK THERMAL TRANSMITTER.                 NG       Repair or replace.
                                                          c
          Refer to ``THERMAL TRANSMITTER
          CHECK'' (EL-2071).

                                OK

                            .
          CHECK HARNESS.                             NG       Repair harness or connec-
                                                          c
          1. Disconnect combination meter connec-             tor.
             tor N4 and thermal transmitter con-
             nector.
          2. Check harness continuity between
             combination meter terminal V and
                                          5
             thermal transmitter terminal V .
                                          1
          Continuity should exist.
          3. Check continuity between combination
             meter terminal V and ground.
                             5
          Continuity should not exist.

                                OK
                            .
SEL426W   Thermal transmitter is OK.



                 EL-2064
                                               METER AND GAUGES

                                                      Trouble Diagnoses/Models without
                                                      Tachometer

PRELIMINARY CHECK
       CHECK-IN


          .
 Can Diagnosis mode       No       Do meter warning          Yes
                               c
 be activated? Refer to            lamps operate?
 ``Meter/Gauge Opera-
                                               No
 tion and Odo/Trip                                                                          Can Diagnosis mode
 Meter Segment                                                                              be activated?
 Check in Diagnosis
                                                                                              m    Yes       No
 Mode'', EL-2058.

              Yes
                                           .
                                   Check power supply
                                   and ground circuit.
                                   Refer to ``POWER
                                   SUPPLY AND
                                   GROUND CIRCUIT
                                   CHECK'', EL-2067.

          .
 Check meter/gauge
                          b
 operation in Diagno-
 sis mode.




          .                                                                .                             .            .
 Malfunction is indi-                                              No malfunction is        Replace unified meter control
 cated in Diagnosis                                                indicated in Diagnosis   unit.
 mode.                                                             mode.


          .                                                                 .
 Check the following:                                              SYMPTOM CHART 2
 q Screws securing the                                             Refer to EL-2066.
   malfunctioning         NG
   meter/gauge
   (The screws are
   located behind the
   combination meter.
   For details refer to
   EL-2070.)

              OK
          .                                              .
 SYMPTOM CHART 1                   Retighten the loose screw.
 Refer to EL-2066.




                                                             EL-2065
                                                       METER AND GAUGES
                                                          Trouble Diagnoses/Models without
                                                          Tachometer (Cont'd)
Before starting trouble diagnoses below, perform PRELIMINARY CHECK, EL-2065.

SYMPTOM CHART 1 (MALFUNCTION IS INDICATED IN DIAGNOSIS MODE)
          Symptom                                   Possible causes                                        Repair order

Odo/trip meter indicate(s) mal-   q   Unified meter control unit                q   Replace unified meter control unit.
function in Diagnosis mode.

Multiple meter/gauge indicate
malfunction in Diagnosis
mode.

One of speedometer/               q   Meter/Gauge                               1. Check resistance of meter/gauge indicating malfunction. If
tachometer/fuel gauge/water       q   Unified meter control unit                   the resistance is NG, replace the meter/gauge. Refer to
temp. gauge indicates mal-                                                         ``METER/GAUGE RESISTANCE CHECK'', EL-2070.
function in Diagnosis mode.                                                     2. If the resistance is OK, replace unified meter control unit.


SYMPTOM CHART 2 (NO MALFUNCTION IS INDICATED IN DIAGNOSIS MODE)
          Symptom                                   Possible causes                                        Repair order

One/or more of speedometer/ 1. Sensor                                           1. Check the sensor for malfunctioning meter/gauge.
tachometer/fuel gauge/water       - Vehicle speed signal                           INSPECTION/VEHICLE SPEED SENSOR (Refer to
temp. gauge is malfunctioning.    - Fuel gauge                                     EL-2068.)
                                  - Water temp. gauge                              INSPECTION/FUEL LEVEL SENSOR (Refer to EL-2064.)
                               2. Unified meter control unit                       INSPECTION/THERMAL TRANSMITTER (Refer to
                                                                                   EL-2069.)
                                                                                2. Replace unified meter control unit.




                                                                      EL-2066
      METER AND GAUGES
         Trouble Diagnoses/Models without
         Tachometer (Cont'd)
          POWER SUPPLY AND GROUND CIRCUIT CHECK
          Power supply circuit check
                   Terminals                   Ignition switch position
                               @      OFF               ACC                ON
                                     Battery           Battery            Battery
              21
              V             Ground
                                     voltage           voltage            voltage
                                                                          Battery
SEL428W       22
              V             Ground     0V                0V
                                                                          voltage

          If NG, check the following.
          q 7.5A fuse [No. 3 , located in fuse block (J/B)]
          q 10A fuse [No. 20 , located in fuse block (J/B)]
          q Harness for open or short between fuse and combination
              meter




          Ground circuit check
                      Terminals                          Continuity
                     23
                     V    - Ground                            Yes




SEL429W




              EL-2067
      METER AND GAUGES
         Trouble Diagnoses/Models without
         Tachometer (Cont'd)
           INSPECTION/VEHICLE SPEED SENSOR

          CHECK VEHICLE SPEED SENSOR                OK       Vehicle speed sensor is
                                                         c
          OUTPUT.                                            OK.
          1. Remove vehicle speed sensor from
             transmission.
          2. Check voltage between combination
             meter terminals V and V while
                               24     37
             quickly turning speed sensor pinion.
             Voltage: Approx. 0.5V

                                NG

                            .
          CHECK VEHICLE SPEED SENSOR.               NG       Replace vehicle speed
                                                         c
          Check resistance between vehicle speed             sensor.
          sensor terminals V and V .
                           1      2
          Resistance: Approx. 250

                                OK
                            .
SEL430W   Check harness or connector between
          speedometer and vehicle speed sensor.




SEL118V




                 EL-2068
      METER AND GAUGES
         Trouble Diagnoses/Models without
         Tachometer (Cont'd)
           INSPECTION/FUEL LEVEL SENSOR

          CHECK GROUND CIRCUIT FOR FUEL              NG       Repair harness or connec-
                                                          c
          LEVEL SENSOR UNIT.                                  tor.
          Check harness continuity between fuel
          level sensor unit terminal V and ground.
                                     1
          Continuity should exist.

                                OK
SEL424W                     .
          CHECK FUEL LEVEL SENSOR UNIT.              NG       Repair or replace.
                                                          c
          Refer to ``FUEL LEVEL SENSOR UNIT                   Refer to FE section.
          CHECK'' (EL-2070).

                                OK

                            .
          CHECK HARNESS.                             NG       Repair harness or connec-
                                                          c
          1. Disconnect combination meter connec-             tor.
             tor N10 and fuel level sensor unit
             connector.
          2. Check harness continuity between
SEL431W      combination meter terminal V and
                                           35
             fuel level sensor unit terminal V .
                                              3
          Continuity should exist.
          3. Check continuity between combination
             meter terminal V and ground.
                             35
          Continuity should not exist.

                                OK
                            .
          Fuel level sensor is OK.




           INSPECTION/THERMAL TRANSMITTER
          CHECK THERMAL TRANSMITTER.                 NG       Repair or replace.
                                                          c
          Refer to ``THERMAL TRANSMITTER
          CHECK'' (EL-2071).

                                OK

                            .
          CHECK HARNESS.                             NG       Repair harness or connec-
                                                          c
          1. Disconnect combination meter connec-             tor.
             tor N10 and thermal transmitter con-
             nector.
          2. Check harness continuity between
             combination meter terminal V and
                                          34
             thermal transmitter terminal V .
                                           1
          Continuity should exist.
            3. Check continuity between combina-
               tion meter terminal V and ground.
                                    34
            Continuity should not exist.

                                OK
                            .
          Thermal transmitter is OK.

SEL432W


                 EL-2069
     METER AND GAUGES

         Electrical Components Inspection
         METER/GAUGE RESISTANCE CHECK
         1. Disconnect FPC connector (Combination meter with tachom-
            eter). Refer to EL-2059.
         2. Check resistance between terminals (the points of installa-
            tion screws) of meter/gauge after removing meter/gauge.

                        Screws                                     Resistance
           Tachometer           Fuel/Temp. gauge

                A-C                  A-C                  Approx. 140 - Approx. 260
                B-D                  B-C                  Approx. 230 - Approx. 310




                                                                                     SEL638W




                                                                                     SEL433W


         FUEL LEVEL SENSOR UNIT CHECK
         q For removal, refer to FE section.
         Check the resistance between terminals                   1
                                                                  V   and   V.
                                                                            3

           Ohmmeter                    Float position   mm (in)                    Resistance
                                                  60! (13-1/4      80! (17-5/8       value
          (+)     (-)
                                                 Imp gal) tank    Imp gal) tank
                           *1         Full         253 (9.96)       77 (3.03)     Approx. 4 - 6

          V3      V1       *2         1/2          130 (5.12)      191 (7.52)       27 - 35
                           *3        Empty         27 (1.06)      299 (11.77)       78 - 85
GEL256
          *1 and *3: When float rod is in contact with stopper.




                EL-2070
       METER AND GAUGES
          Electrical Components Inspection (Cont'd)
           THERMAL TRANSMITTER CHECK
           Check the resistance between the terminals of thermal transmit-
           ter and body ground.

                   Water temperature                 Resistance
                     60



◦ Jabse Service Manual Search 2023 ◦ Jabse PravopisonTap.bg ◦ Other service manual resources online : FixyaeServiceinfo
