Image preview - the first page of the document
>> Download WCS documenatation <<
Text preview - extract from the document
DRIVER INFORMATION & MULTIMEDIA
A
SECTION
WARNING CHIME SYSTEM
WCS B
C
D
E
CONTENTS
BASIC INSPECTION ................................... 3
. PARKING BRAKE RELEASE WARNING CHIME F
: System Description ...............................................11
.
DIAGNOSIS AND REPAIR WORKFLOW ......... 3
. PARKING BRAKE RELEASE WARNING CHIME
Work Flow ................................................................ 3
. : Component Parts Location ...................................11. G
PARKING BRAKE RELEASE WARNING CHIME
FUNCTION DIAGNOSIS .............................. 5
. : Component Description ........................................12
.
WARNING CHIME SYSTEM .............................. 5
. KEY WARNING CHIME ............................................12 . H
KEY WARNING CHIME : System Diagram ............12 .
WARNING CHIME SYSTEM ...................................... 5 .
KEY WARNING CHIME : System Description .......12 .
WARNING CHIME SYSTEM : System Diagram ...... 5
KEY WARNING CHIME : Component Parts Loca- I
WARNING CHIME SYSTEM : System Description
tion ..........................................................................13
.
...... 5
KEY WARNING CHIME : Component Description 13 ....
WARNING CHIME SYSTEM : Component Parts
Location .................................................................... 6
. DIAGNOSIS SYSTEM (METER) ....................... 14 J
WARNING CHIME SYSTEM : Component De- CONSULT-III Function (METER/M&A) ...................14
.
scription .................................................................... 6
.
DIAGNOSIS SYSTEM (BCM) ........................... 17 K
LIGHT REMINDER WARNING CHIME ...................... 7 .
LIGHT REMINDER WARNING CHIME : System COMMON ITEM ........................................................17
.
Diagram .................................................................... 7
. COMMON ITEM : CONSULT-III Function (BCM -
LIGHT REMINDER WARNING CHIME : System COMMON ITEM) ....................................................17
. L
Description ............................................................... 7
.
LIGHT REMINDER WARNING CHIME : Compo- BUZZER ....................................................................17
.
nent Parts Location .................................................. 8
. BUZZER : CONSULT-III Function (BCM - BUZZ-
M
LIGHT REMINDER WARNING CHIME : Compo- ER) .........................................................................18
.
nent Description ....................................................... 8
.
COMPONENT DIAGNOSIS ........................ 19
.
SEAT BELT REMINDER WARNING CHIME ............. 8 . WCS
SEAT BELT REMINDER WARNING CHIME :
POWER SUPPLY AND GROUND CIRCUIT .... 19
System Diagram ....................................................... 9
. COMBINATION METER ...........................................19
.
SEAT BELT REMINDER WARNING CHIME : COMBINATION METER : Diagnosis Procedure ....19 O
System Description .................................................. 9
.
SEAT BELT REMINDER WARNING CHIME : BCM (BODY CONTROL MODULE) .........................19 .
Component Parts Location ..................................... 10
. BCM (BODY CONTROL MODULE) : Diagnosis
Procedure ...............................................................19
. P
SEAT BELT REMINDER WARNING CHIME :
Component Description .......................................... 10
.
METER BUZZER CIRCUIT ............................... 21
PARKING BRAKE RELEASE WARNING CHIME .... 10 Description ..............................................................21
.
PARKING BRAKE RELEASE WARNING CHIME Component Function Check ...................................21 .
: System Diagram ................................................... 11
. Diagnosis Procedure ..............................................21 .
Revision: 2008 January WCS-1 2008 Rogue
SEAT BELT BUCKLE SWITCH SIGNAL CIR- THE LIGHT REMINDER WARNING DOES
CUIT .................................................................. 22
. NOT SOUND ..................................................... 65
.
Description ............................................................. 22
. Description ............................................................. 65
.
Component Function Check .................................. 22 . Diagnosis Procedure .............................................. 65 .
Diagnosis Procedure ............................................. 22 .
Component Inspection ........................................... 23 . THE SEAT BELT REMINDER WARNING
DOES NOT SOUND ......................................... 66
.
PARKING BRAKE SWITCH SIGNAL CIR- Description ............................................................. 66
.
CUIT .................................................................. 24
. Trouble diagnosis procedure ................................. 66 .
Description ............................................................. 24
.
Diagnosis Procedure ............................................. 24 . THE PARKING BRAKE RELEASE WARNING
Component Inspection ........................................... 24 . DOES NOT SOUND ......................................... 67
.
Description ............................................................. 67
.
WARNING CHIME SYSTEM ............................ 25
. Diagnosis Procedure .............................................. 67 .
Wiring Diagram - WARNING CHIME - ................... 25
.
THE KEY WARNING DOES NOT SOUND ...... 68
.
ECU DIAGNOSIS ....................................... 29
. Description ............................................................. 68
.
Diagnosis Procedure .............................................. 68 .
COMBINATION METER ................................... 29
.
Reference Value .................................................... 29. PRECAUTION ............................................ 69
Wiring Diagram - METER - .................................... 34 .
Fail Safe ................................................................ 41
. PRECAUTIONS ................................................ 69
.
DTC Index ............................................................. 42
.
FOR USA AND CANADA ........................................ 69
.
BCM (BODY CONTROL MODULE) ................. 43
. FOR USA AND CANADA : Precaution for Supple-
Reference Value .................................................... 43. mental Restraint System (SRS) "AIR BAG" and
Wiring Diagram - BCM - ........................................ 58 . "SEAT BELT PRE-TENSIONER" .......................... 69.
Fail Safe ................................................................ 62
.
FOR MEXICO ........................................................... 69
.
DTC Inspection Priority Chart ............................. 63 .
FOR MEXICO : Precaution for Supplemental Re-
DTC Index ............................................................. 63
. straint System (SRS) "AIR BAG" and "SEAT BELT
SYMPTOM DIAGNOSIS ............................ 65
. PRE-TENSIONER" ................................................ 69.
Revision: 2008 January WCS-2 2008 Rogue
DIAGNOSIS AND REPAIR WORKFLOW
< BASIC INSPECTION >
BASIC INSPECTION A
DIAGNOSIS AND REPAIR WORKFLOW
Work Flow INFOID:0000000001686506
B
OVERALL SEQUENCE
C
D
E
F
G
H
I
J
K
L
JSNIA0456GB M
DETAILED FLOW
1.OBTAIN INFORMATION ABOUT SYMPTOM WCS
Interview the customer to obtain as much information as possible about the conditions and environment under
which the malfunction occurred.
O
>> GO TO 2.
2.CHECK SYMPTOM P
