Image preview - the first page of the document
GW


>> Download GW documenatation <<

Text preview - extract from the document
BODY EXTERIOR, DOORS, ROOF & VEHICLE SECURITY

                                                                                                                                                                      A




                                                                                              SECTION
                                                                            GLASS & WINDOW SYSTEM
                                                                                                                          GW                                          B



                                                                                                                                                                      C


                                                                                                                                                                      D


                                                                                                                                                                      E
                                                                    CONTENTS
SYMPTOM DIAGNOSIS .............................. 2
                                            .                                          Commercial Service Tools ....................................11
                                                                                                                                                .                     F

SQUEAK AND RATTLE TROUBLE DIAG-                                                      ON-VEHICLE REPAIR ................................ 12
                                                                                                                                    .
NOSES ............................................................... 2
                                                                .                                                                                                     G
  Work Flow ................................................................ 2
                                                                      .
                                                                                     WINDSHIELD GLASS ....................................... 12
  Inspection Procedure ............................................... 4
                                                                      .                Exploded View ........................................................12
                                                                                                                                                             .
  Diagnostic Worksheet .............................................. 6
                                                                      .                Removal and Installation ........................................12   .
                                                                                       Inspection ...............................................................14
                                                                                                                                                             .        H
PRECAUTION .............................................. 8
                                                     .
                                                                                     SIDE WINDOW GLASS .................................... 15
PRECAUTIONS .................................................. 8
                                                         .                             Exploded View ........................................................15
                                                                                                                                                             .
                                                                                                                                                                      I
                                                                                       Removal and Installation ........................................15   .
FOR MEXICO ............................................................. 8
                                                                  .                    Inspection ...............................................................16
                                                                                                                                                             .
 FOR MEXICO : Precaution for Supplemental Re-
 straint System (SRS) "AIR BAG" and "SEAT BELT                                       BACK DOOR WINDOW GLASS ...................... 17                                 J
 PRE-TENSIONER" .................................................. 8
                                                                  .                    Exploded View ........................................................17
                                                                                                                                                             .
 FOR MEXICO : Precaution Necessary for Steer-                                          Removal and Installation ........................................17   .
 ing Wheel Rotation After Battery Disconnect ........... 8        .                    Inspection ...............................................................18
                                                                                                                                                             .        GW
 FOR MEXICO : Precaution for Procedure without
 Cowl Top Cover ....................................................... 9
                                                                  .
                                                                                     FRONT DOOR GLASS ..................................... 19
 FOR MEXICO : Precaution for Work ........................ 9      .                    Exploded View ........................................................19
                                                                                                                                                         .
                                                                                       Removal and Installation ........................................19
                                                                                                                                                         .            L
 FOR MEXICO : Handling for Adhesive and Primer 9                  ......
                                                                                       Inspection and Adjustment .....................................20 .
FOR USA AND CANADA ........................................... 9          .
 FOR USA AND CANADA : Precaution for Supple-                                         FRONT REGULATOR ....................................... 22
                                                                                                                                                                      M
 mental Restraint System (SRS) "AIR BAG" and                                           Exploded View ........................................................22
                                                                                                                                                         .
 "SEAT BELT PRE-TENSIONER" ............................. 9                .            Removal and Installation ........................................22
                                                                                                                                                         .
 FOR USA AND CANADA : Precaution Necessary                                             Disassembly and Assembly ....................................22   .
                                                                                       Inspection and Adjustment .....................................23 .            N
 for Steering Wheel Rotation After Battery Discon-
 nect .......................................................................... 9
                                                                          .          REAR DOOR GLASS ....................................... 25
 FOR USA AND CANADA : Precaution for Proce-                                            Exploded View ........................................................25
                                                                                                                                                         .
 dure without Cowl Top Cover ................................. 10         .                                                                                           O
                                                                                       Removal and Installation ........................................25
                                                                                                                                                         .
 FOR USA AND CANADA : Precaution for Work .... 10                                      Inspection and Adjustment .....................................26 .
 FOR USA AND CANADA : Handling for Adhesive
 and Primer .............................................................. 10
                                                                          .          REAR REGULATOR ......................................... 27                      P
                                                                                       Exploded View ........................................................27
                                                                                                                                                         .
PREPARATION .......................................... 11
                                                   .                                   Removal and Installation ........................................27
                                                                                                                                                         .
PREPARATION .................................................11
                                                         .                             Disassembly and Assembly ....................................28   .
                                                                                       Inspection and Adjustment .....................................28 .
  Special Service Tools ........................................... 11
                                                               .




Revision: 2008 August                                                          GW-1                                                               2009 Rogue
                        SQUEAK AND RATTLE TROUBLE DIAGNOSES
< SYMPTOM DIAGNOSIS >
SYMPTOM DIAGNOSIS
SQUEAK AND RATTLE TROUBLE DIAGNOSES
Work Flow                                                                                            INFOID:0000000004582139




                                                                                                   SBT842




CUSTOMER INTERVIEW
Interview the customer if possible, to determine the conditions that exist when the noise occurs. Use the Diag-
nostic Worksheet during the interview to document the facts and conditions when the noise occurs and any of
customer's comments; refer to GW-6, "Diagnostic Worksheet". This information is necessary to duplicate the
conditions that exist when the noise occurs.
