Image preview - the first page of the document
>> Download MA documenatation <<
Text preview - extract from the document
MAINTENANCE
A
SECTION
MAINTENANCE
MA B
C
D
E
CONTENTS
PREPARATION ........................................... 3
. FOR NORTH AMERICA : Anti-Freeze Coolant F
Mixture Ratio ..........................................................18
.
PREPARATION .................................................. 3
.
FOR MEXICO ............................................................18
.
FOR NORTH AMERICA ............................................. 3 . G
FOR MEXICO : Fluids and Lubricants ....................18 .
FOR NORTH AMERICA : Special Service Tool ....... 3 . FOR MEXICO : SAE Viscosity Number ..................19 .
FOR NORTH AMERICA : Commercial Service FOR MEXICO : Engine Coolant Mixture Ratio .......19 .
Tool .......................................................................... 3
. H
ENGINE MAINTENANCE ................................. 20
FOR MEXICO ............................................................. 3
.
FOR MEXICO : Special Service Tool ....................... 4 . DRIVE BELTS ...........................................................20
.
FOR MEXICO : Commercial Service Tool ............... 4 . DRIVE BELTS : Exploded View .............................20 . I
FOR MEXICO : Pre-Delivery Inspection Item .......... 4 . DRIVE BELTS : Checking ......................................20 .
DRIVE BELTS : Tension Adjustment .....................20 .
ON-VEHICLE MAINTENANCE .................... 7
. J
ENGINE COOLANT ..................................................20
.
GENERAL MAINTENANCE ............................... 7
. ENGINE COOLANT : Inspection ............................20 .
ENGINE COOLANT : Draining ...............................21 .
FOR NORTH AMERICA ............................................. 7 . ENGINE COOLANT : Refilling ................................22
. K
FOR NORTH AMERICA : Explanation of General ENGINE COOLANT : Flushing ...............................23 .
Maintenance ............................................................. 7
.
RADIATOR CAP .......................................................24
. L
FOR MEXICO ............................................................. 8
. RADIATOR CAP : Inspection .................................24 .
FOR MEXICO : General Maintenance ..................... 8 .
RADIATOR ................................................................25
.
PERIODIC MAINTENANCE ..............................10
. RADIATOR : Inspection ..........................................25 . M
FOR NORTH AMERICA ........................................... 10 . FUEL LINES ..............................................................25
.
FOR NORTH AMERICA : Introduction of Periodic FUEL LINES : Inspection ........................................26 .
Maintenance ........................................................... 10
. N
FOR NORTH AMERICA : Schedule 1 ................... 10 . AIR CLEANER FILTER ............................................26
.
FOR NORTH AMERICA : Schedule 2 ................... 12 . AIR CLEANER FILTER : Removal and Installation
....26 O
FOR MEXICO ........................................................... 13
.
FOR MEXICO : Periodic Maintenance ................... 13 . ENGINE OIL ..............................................................26
.
ENGINE OIL : Draining ...........................................26 .
RECOMMENDED FLUIDS AND LUBRI- ENGINE OIL : Refilling ...........................................27. MA
CANTS ...............................................................17
.
OIL FILTER ...............................................................27
.
FOR NORTH AMERICA ........................................... 17 . OIL FILTER : Removal and Installation ..................27 .
FOR NORTH AMERICA : Fluids and Lubricants .... 17 OIL FILTER : Inspection .........................................28 .
FOR NORTH AMERICA : Engine Oil Recommen-
dation ..................................................................... 17
. SPARK PLUG ...........................................................28
.
SPARK PLUG : Removal and Installation ..............28 .
Revision: 2008 August MA-1 2009 Rogue
SPARK PLUG : Inspection .................................... 28
. STEERING GEAR AND LINKAGE .......................... 38
.
STEERING GEAR AND LINKAGE : Inspection ..... 38 .
EVAP VAPOR LINES ............................................... 29
.
EVAP VAPOR LINES : Inspection ......................... 29 . AXLE AND SUSPENSION PARTS .......................... 38
.
AXLE AND SUSPENSION PARTS : Inspection .... 38 .
CHASSIS MAINTENANCE ............................... 30
.
DRIVE SHAFT .......................................................... 38
.
EXHAUST SYSTEM ................................................. 30
. DRIVE SHAFT : Inspection .................................... 39 .
EXHAUST SYSTEM : Inspection .......................... 30 .
BODY MAINTENANCE .................................... 40
.
CVT FLUID ............................................................... 30
.
CVT FLUID : Inspection ......................................... 30 . LOCKS, HINGES AND HOOD LATCH .................... 40 .
CVT FLUID : Changing .......................................... 31 . LOCKS, HINGES AND HOOD LATCH : Lubricat-
ing .......................................................................... 40
.
TRANSFER OIL ....................................................... 32
.
TRANSFER OIL : Inspection ................................. 32 . SEAT BELT, BUCKLES, RETRACTORS, AN-
TRANSFER OIL : Draining .................................... 32 . CHORS AND ADJUSTERS ..................................... 40
.
TRANSFER OIL : Refilling ..................................... 32
. SEAT BELT, BUCKLES, RETRACTORS, AN-
CHORS AND ADJUSTERS : Inspection ................ 40 .
REAR PROPELLER SHAFT .................................... 33
.
REAR PROPELLER SHAFT : Inspection .............. 33 . SERVICE DATA AND SPECIFICATIONS
REAR DIFFERENTIAL GEAR OIL .......................... 33
. (SDS) .......................................................... 41
REAR DIFFERENTIAL GEAR OIL : Inspection ..... 33 . SERVICE DATA AND SPECIFICATIONS
REAR DIFFERENTIAL GEAR OIL : Draining ........ 33.
(SDS) ................................................................ 41
.
REAR DIFFERENTIAL GEAR OIL : Refilling ........ 34
.
DRIVE BELTS .......................................................... 41
.
WHEELS (BONDING WEIGHT TYPE) .................... 34 .
DRIVE BELTS : Drive belt ..................................... 41 .
WHEELS (BONDING WEIGHT TYPE) : Adjust-
ment ....................................................................... 34
. ENGINE COOLANT ................................................. 41 .
ENGINE COOLANT : Periodical Maintenance
BRAKE FLUID LEVEL AND LEAKS ....................... 36
.
Specification ........................................................... 41
.
BRAKE FLUID LEVEL AND LEAKS : Inspection ... 36
ENGINE OIL ............................................................. 41
.
BRAKE LINES AND CABLES ................................. 36
.
ENGINE OIL :
BRAKE LINES AND CABLES : Inspection ............ 36 .
Periodical Maintenance Specification ................... 41 .
BRAKE FLUID ......................................................... 36
.
SPARK PLUG .......................................................... 41
.
BRAKE FLUID : Changing ..................................... 37 .
SPARK PLUG : Spark Plug ................................... 41 .
DISC BRAKE ........................................................... 37
.
ROAD WHEEL ......................................................... 41
.
DISC BRAKE : Inspection ..................................... 37 .
ROAD WHEEL : Road Wheel ................................ 41 .
DISC BRAKE : Front Disc Brake ........................... 37 .
DISC BRAKE : Rear Disc Brake ............................ 38 .
Revision: 2008 August MA-2 2009 Rogue
PREPARATION
< PREPARATION >
PREPARATION A
PREPARATION
FOR NORTH AMERICA
B
FOR NORTH AMERICA : Special Service Tool INFOID:0000000004232501
The actual shapes of Kent-Moore tools may differ from those of special service tools illustrated here. C
Tool number
(Kent-Moore No.) Description
Tool name
D
KV10115801 Removing and installing oil filter
(J-38956) a: 64.3 mm (2.531 in)
Oil filter wrench
E
F
S-NT375
FOR NORTH AMERICA : Commercial Service Tool INFOID:0000000004232502
G
(Kent-Moore No.)
Description
Tool name
H
( -- ) Loosening nuts and bolts
Power tool
I
J
PBIC0190E
( -- ) Checking radiator and radiator cap
Radiator cap tester
K
L
PBIC1982E
( -- ) Adapting radiator cap tester to radiator cap M
Radiator cap tester adapter and radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia. N
Unit: mm (in)
S-NT564 O
( -- ) Removing and installing spark plug
Spark plug wrench
MA
PBIC2982E
FOR MEXICO
Revision: 2008 August MA-3 2009 Rogue
PREPARATION
< PREPARATION >
FOR MEXICO : Special Service Tool INFOID:0000000004232503
Tool number
Description
Tool name
KV10115801 Removing and installing oil filter
Oil filter wrench a: 64.3 mm (2.531 in)
S-NT375
FOR MEXICO : Commercial Service Tool INFOID:0000000004232504
Tool name Description
Power tool Loosening nuts and bolts
PBIC0190E
Radiator cap tester Checking radiator and radiator cap
PBIC1982E
Radiator cap tester adapter Adapting radiator cap tester to radiator cap
and radiator filler neck
a: 28 (1.10) dia.
b: 31.4 (1.236) dia.
c: 41.3 (1.626) dia.
Unit: mm (in)
S-NT564
Spark plug wrench Removing and installing spark plug
PBIC2982E
FOR MEXICO : Pre-Delivery Inspection Item INFOID:0000000004232505
Shown below are Pre-delivery Inspection Items required for the new vehicle. It is recommended that
necessary items other than those listed here be added, paying due regard to the conditions in each
country.
Perform applicable items on each model. Consult text of this section for specifications.
UNDER HOOD -- engine off
Radiator coolant level and coolant hose connections for leaks
Revision: 2008 August MA-4 2009 Rogue
PREPARATION
< PREPARATION >
Battery fluid level, specific gravity and conditions of battery terminals
A
Drive belts tension
Fuel filter for water or dusts (Diesel only), and fuel lines and connections for leaks
Engine oil level and oil leaks B
Clutch and brake reservoir fluid level and fluid lines for leaks
Windshield and rear window washer and headlamp cleaner reservoir fluid level
C
Power steering reservoir fluid level and hose connections for leaks
ON INSIDE AND OUTSIDE
Remove front spring/strut spacer (If applicable)
D
Operation of all instruments, gauges, lights and accessories
Operation of horn(s), wiper and washer
Steering lock for operation E
Check air conditioner for gas leaks
Front and rear seats, and seat belts for operation
F
All moldings, trims and fittings for fit and alignment
All windows for operation and alignment
Hood, trunk lid, door panels for fit and alignment G
Latches, keys and locks for operation
Weatherstrips for adhesion and fit
H
Headlamp aiming
Tighten wheel nuts (Inc. inner nuts if applicable)
Tire pressure (Inc. spare tire) I
Check front wheels for toe-in
Install clock/voltmeter/room lamp fuse (If applicable)
J
Install deodorizing filter to air conditioner (If applicable)
Remove wiper blade protectors (If applicable)
UNDER BODY
K
Manual transmission/transaxle, transfer and differential gear oil level
Brake and fuel lines and oil/fluid reservoirs for leaks
Tighten bolts and nuts of steering linkage and gear box, suspension, propeller shafts and drive shafts L
Tighten rear body bolts and nuts (Models with wooden bed only)
ROAD TEST
Clutch operation M
Parking brake operation
Service brake operation N
Automatic transmission/transaxle shift timing and kickdown
Steering control and returnables
Engine performance O
Squeaks and rattles
ENGINE OPERATING AND HOT
MA
Adjust idle speed
Automatic transmission/transaxle fluid level
Engine idling and stop knob operation (Diesel only)
FINAL INSPECTION
Install necessary parts (outside mirror, wheel covers, seat belts, mat, carpet or mud flaps)
Inspect for interior and exterior metal and paint damage
Revision: 2008 August MA-5 2009 Rogue
PREPARATION
< PREPARATION >
Check for spare tire, jack, tools (wheel chock), and literature
Wash, clean interior and exterior
: Not applicable to this model
Revision: 2008 August MA-6 2009 Rogue
GENERAL MAINTENANCE
< ON-VEHICLE MAINTENANCE >
ON-VEHICLE MAINTENANCE A
GENERAL MAINTENANCE
FOR NORTH AMERICA
B
FOR NORTH AMERICA : Explanation of General Maintenance INFOID:0000000004232506
General maintenance includes those items which should be checked during the normal day-to-day operation C
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform
checks and inspections themselves or have their NISSAN dealers do them.
OUTSIDE THE VEHICLE
D
The maintenance items listed here should be performed from time to time, unless otherwise specified.
Item Reference page
Tires Check the pressure with a gauge often and always prior to long distance trips.
Adjust the pressure in all tires, including the spare, to the pressure specified. WT-81
E
Check carefully for damage, cuts or excessive wear.
Wheel nuts When checking the tires, make sure no nuts are missing, and check for any loose
--
nuts. Tighten if necessary. F
Tire rotation Tires should be rotated every 12,000 km (7,500 miles). MA-34
Tire Pressure Monitor-
ing System (TPMS) Replace the TPMS transmitter grommet seal, valve core and cap when the tires G
WT-8
transmitter compo- are replaced due to wear or age.
nents
Wheel alignment and If the vehicle should pull to either side while driving on a straight and level road, H
balance or if you detect uneven or abnormal tire wear, there may be a need for wheel
FSU-8, RSU-6, MA-34
alignment. If the steering wheel or seat vibrates at normal highway speeds,
wheel balancing may be needed.
I
Clean the windshield on a regular basis. Check the windshield at least every six
Windshield --
months for cracks or other damage. Repair as necessary.
Windshield wiper
Check for cracks or wear if they do not wipe properly. -- J
blades
Doors and engine Check that all doors and the engine hood operate smoothly as well as the back
hood door, trunk lid and glass hatch. Also make sure that all latches lock securely. Lu-
bricate if necessary. Make sure that the secondary latch keeps the hood from K
MA-40
opening when the primary latch is released.
When driving in areas using road salt or other corrosive materials, check lubrica-
tion frequently.
L
Lamps Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and oth-
er lamps are all operating properly and installed securely. Also check headlamp --
aim. Clean the headlamps on a regular basis.
M
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle,
etc.
Item Reference page N
Warning lamps and
Make sure that all warning lamps and chimes are operating properly. --
chimes
Windshield wiper and Check that the wipers and washer operate properly and that the wipers do not O
--
washer streak.
Windshield defroster Check that the air comes out of the defroster outlets properly and in sufficient
--
quantity when operating the heater or air conditioner.
MA
Steering wheel Check that it has the specified play. Check for changes in the steering condition,
such as excessive play, hard steering or strange noises. --
Free play: Less than 35 mm (1.38 in)
Revision: 2008 August MA-7 2009 Rogue
GENERAL MAINTENANCE
< ON-VEHICLE MAINTENANCE >
Item Reference page
Seats Check seat position controls such as seat adjusters, seatback recliner, etc. to
make sure they operate smoothly and that all latches lock securely in every posi-
tion. Check that the head restrains move up and down smoothly and that the locks --
(if equipped) hold securely in all latched positions. Check that the latches lock se-
curely for folding-down rear seatbacks.
Seat belts Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and
retractors) operate properly and smoothly and are installed securely. Check the MA-40
belt webbing for cuts, fraying, wear or damage.
Accelerator pedal Check the pedal for smooth operation and make sure the pedal does not catch or
--
require uneven effort. Keep the floor mats away from the pedal.
Brakes Check that the brake does not pull the vehicle to one side when applied. --
Brake pedal and Check the pedal for smooth operation and make sure it has the proper distance
booster under it when depressed fully. Check the brake booster function. Be sure to keep BR-9, BR-15
the floor mats away from the pedal.
Parking brake Check that the lever or the pedal has the proper travel and make sure that the ve-
PB-3
hicle is held securely on a fairly steep hill when only the parking brake is applied.
CVT P (Park) position On a fairly steep hill check that the vehicle is held securely with the selector lever
--
mechanism in the P (Park) position without applying any brakes.
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
Item Reference page
Windshield washer
Check that there is adequate fluid in the tank. --
fluid
Engine coolant level Check the coolant level when the engine is cold. CO-9
Radiator and hoses Check the front of the radiator and clean off any dirt, insects, leaves, etc., that
may have accumulated. Make sure the hoses have no cracks, deformation, de- --
terioration or loose connections.
Brake fluid level Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the
MA-36
reservoir.
Battery Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines.
Vehicles operated in high temperatures or under severe conditions require fre- PG-3
quent checks of the battery fluid level.
Engine drive belts Make sure that no belt is frayed, worn, cracked or oily. MA-20
Engine oil level Check the level on the oil level gauge after parking the vehicle on a level spot and
LU-5
turning off the engine.
Exhaust system Make sure there are no loose supports, cracks or holes. If the sound of the ex-
haust seems unusual or there is a smell of exhaust fumes, immediately locate MA-30
the trouble and correct it.
Underbody The underbody is frequently exposed to corrosive substances such as those
used on icy roads or to control dust. It is very important to remove these sub-
stances, otherwise rust will form on the floor pan, frame, fuel lines and around the
--
exhaust system. At the end of winter, the underbody should be thoroughly
flushed with plain water, being careful to clean those areas where mud and dirt
can easily accumulate.
Fluid leaks Check under the vehicle for fuel, oil, water or other fluid leaks after the vehicle
has been parked for a while. Water dripping from the air conditioner after use is
--
normal. If you should notice any leaks or gasoline fumes are evident, check for
the cause and correct it immediately.
FOR MEXICO
FOR MEXICO : General Maintenance INFOID:0000000004232507
General maintenance includes those items which should be checked during the normal day-to-day operation
of the vehicle. They are essential if the vehicle is to continue operating properly. The owners can perform the
checks and inspections themselves or they can have their NISSAN dealers do them for a normal charge.
Revision: 2008 August MA-8 2009 Rogue
GENERAL MAINTENANCE
< ON-VEHICLE MAINTENANCE >
OUTSIDE THE VEHICLE
The maintenance items listed here should be performed from time to time, unless otherwise specified.
A
Item Reference page
Tires Check the pressure with a gauge often and always prior to long distance trips.
Adjust the pressure in all tires, including the spare, to the pressure specified. WT-81
Check carefully for damage, cuts or excessive wear.
B
Windshield wiper
Check for cracks or wear if not functioning correctly. --
blades
C
Doors and engine Check that all doors and the engine hood operate smoothly as well as the back
hood door, trunk lid and glass hatch. Also make sure that all latches lock securely. Lu-
bricate if necessary. Make sure that the secondary latch keeps the hood from
MA-40
opening when the primary latch is released. D
When driving in areas using road salt or other corrosive materials, check for lu-
brication frequently.
Tire rotation Tires should be rotated every 10,000 km (6,000 miles) for 2WD models and every
MA-34 E
5,000 km (3,000 miles) for 4WD models.
INSIDE THE VEHICLE
The maintenance items listed here should be checked on a regular basis, such as when performing periodic maintenance, cleaning the vehicle,
etc. F
Item Reference page
Lamps Make sure that the headlamps, stop lamps, tail lamps, turn signal lamps, and oth-
er lamps are all operating properly and installed securely. Also check headlamp -- G
aim.
Warning lamps and
Make sure that all warning lamps and chimes are operating properly. --
chimes H
Steering wheel Check that it has the specified play.
Check for changes in the steering conditions, such as excessive free play, hard
--
steering or strange noises.
Free play: Less than 35 mm (1.38 in) I
Seat belts Check that all parts of the seat belt system (e.g. buckles, anchors, adjusters and
retractors) operate properly and smoothly, and are installed securely. Check the MA-40
belt webbing for cuts, fraying, wear or damage. J
UNDER THE HOOD AND VEHICLE
The maintenance items listed here should be checked periodically (e.g. each time you check the engine oil or refuel).
Item Reference page K
Windshield washer
Check that there is adequate fluid in the tank. --
fluid
Engine coolant level Check the coolant level when the engine is cold. MA-20 L
Check the level after parking the vehicle (on a level ground) and turning off the
Engine oil level LU-5
engine.
Brake fluid level Make sure that the brake fluid level is between the "MAX" and "MIN" lines on the M
MA-36
reservoir.
Battery Check the fluid level in each cell. It should be between the "MAX" and "MIN" lines. --
N
O
MA
Revision: 2008 August MA-9 2009 Rogue
PERIODIC MAINTENANCE
< ON-VEHICLE MAINTENANCE >
PERIODIC MAINTENANCE
FOR NORTH AMERICA
FOR NORTH AMERICA : Introduction of Periodic Maintenance INFOID:0000000004232508
Two different maintenance schedules are provided, and should be used, depending upon the conditions in
which the vehicle is mainly operated. After 60,000 miles (96,000 km) or 48 months, continue the periodic
maintenance at the same mileage/time intervals.
Follow Periodic Maintenance Schedule 1 if the driving habits frequently include Emission Control Sys-
one or more of the following driving conditions: tem Maintenance
◦ Jabse Service Manual Search 2025 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
