Image preview - the first page of the document
PWO


>> Download PWO documenatation <<

Text preview - extract from the document
ELECTRICAL & POWER CONTROL

                                                                                                                                                                  A




                                                                         SECTION                   PWO POWER OUTLET
                                                                                                                                                                  B



                                                                                                                                                                  C


                                                                                                                                                                  D


                                                                                                                                                                  E
                                                              CONTENTS
COMPONENT DIAGNOSIS ......................... 2
                                         .                                     FOR MEXICO : Precaution for Supplemental Re-                                       F
                                                                               straint System (SRS) "AIR BAG" and "SEAT BELT
POWER SOCKET .............................................. 2
                                                      .                        PRE-TENSIONER" .................................................. 4
                                                                                                                                           .
  Wiring Diagram - POWER SOCKET - ...................... 2
                                                  .                                                                                                               G
                                                                             ON-VEHICLE REPAIR ................................. 5
                                                                                                                            .
PRECAUTION .............................................. 4
                                                     .
                                                                             POWER SOCKET .............................................. 5
PRECAUTIONS .................................................. 4
                                                         .                                                                                                        H
                                                                             FRONT POWER SOCKET ......................................... 5             .
FOR USA AND CANADA ........................................... 4
                                                        .                     FRONT POWER SOCKET : Exploded View ........... 5                          .
 FOR USA AND CANADA : Precaution for Supple-                                  FRONT POWER SOCKET : Removal and Instal-
 mental Restraint System (SRS) "AIR BAG" and                                  lation ........................................................................ 5
                                                                                                                                                        .         I
 "SEAT BELT PRE-TENSIONER" ............................. 4
                                                        .
                                                                             CONSOLE POWER SOCKET ................................... 5               .
FOR MEXICO ............................................................. 4
                                                                  .           CONSOLE POWER SOCKET : Exploded View ...... 5                           .           J
                                                                              CONSOLE POWER SOCKET : Removal and In-
                                                                              stallation .................................................................. 5
                                                                                                                                                      .
                                                                                                                                                                  K


                                                                                                                                                                  L



                                                                                                                                                                  PWO



                                                                                                                                                                  N



                                                                                                                                                                  O



                                                                                                                                                                  P




Revision: 2008 August                                                 PWO-1                                                                  2009 Rogue
                           POWER SOCKET
< COMPONENT DIAGNOSIS >
COMPONENT DIAGNOSIS
POWER SOCKET
Wiring Diagram - POWER SOCKET -             INFOID:0000000004230980




                                          JCMWM2848GB




Revision: 2008 August             PWO-2        2009 Rogue
                          POWER SOCKET
< COMPONENT DIAGNOSIS >

                                                          A


                                                          B



                                                          C


                                                          D


                                                          E



                                                          F


                                                          G


                                                          H



                                                          I


                                                          J



                                                          K


                                                          L



                                                          PWO



                                                          N



                                                          O

                                         JCMWM2849GB


                                                          P




Revision: 2008 August        PWO-3           2009 Rogue
                                              PRECAUTIONS
< PRECAUTION >
PRECAUTION
PRECAUTIONS
FOR USA AND CANADA
FOR USA AND CANADA : Precaution for Supplemental Restraint System (SRS) "AIR
BAG" and "SEAT BELT PRE-TENSIONER"                                                                   INFOID:0000000004673674



The Supplemental Restraint System such as "AIR BAG" and "SEAT BELT PRE-TENSIONER", used along
with a front seat belt, helps to reduce the risk or severity of injury to the driver and front passenger for certain
types of collision. This system includes seat belt switch inputs and dual stage front air bag modules. The SRS
system uses the seat belt switches to determine the front air bag deployment, and may only deploy one front
air bag, depending on the severity of a collision and whether the front occupants are belted or unbelted.
Information necessary to service the system safely is included in the "SRS AIRBAG" and "SEAT BELT" of this
Service Manual.
WARNING:
