Image preview - the first page of the document
MSA5T0126A27883


>> Download MSA5T0126A27883 documenatation <<

Text preview - extract from the document
                                               DIAGNOSTICS                                          [K100] 5-1
                                                                                                      1. Sunroof


1. Sunroof
                                                    (1) Check roof panel and sunroof glass lid for improper or
                                                    poor sealing.
Entry of water into compartment
                                                    (2) Check drain tube for clogging.
                                                    (3) Check sunroof frame seal and body for improper fit.
                                                    (1) Check sunroof glass lid and roof panel for improper clear-
Booming noise                                       ance.
                                                    (2) Check sunshade and roof trim for improper clearance.
                                                    (1) Check motor for looseness.
                                                    (2) Check gears and bearings for wear.
Abnormal motor noise
                                                    (3) Check cable for wear.
                                                    (4) Check cable pipe for deformities.
                                                    (1) Check guide rail for foreign particles.
                                                    (2) Check guide rail for improper installation.
Failure of sunroof to operate                       (3) Check parts for mutual interference.
(Motor operates properly.)                          (4) Check cable slider for improper clinching.
                                                    (5) Check cable for improper installation.
                                                    (6) Check clutch adjustment nut for improper tightness.
                                                    (1) Check fuse for blowout.
                                                    (2) Check switch for improper function.
                                                    (3) Check motor for incorrect terminal voltage.
Motor does not rotate or rotates improperly.        (4) Check relay for improper operation.
(Use sunroof wrench to check operation.)            (5) Check poor grounding system.
                                                    (6) Check cords for discontinuity and terminals for poor con-
                                                    nections.
                                                    (7) Check limit switch for improper operation.




                                                   45
5-1     DIAGNOSTICS
