Image preview - the first page of the document
MSA5T0126A27924


>> Download MSA5T0126A27924 documenatation <<

Text preview - extract from the document
                                      SERVICE PROCEDURE                                           [W4A0] 5-5
                                                                                               4. Main Harness


4. Main Harness                                             8) Disconnect front sub sensor connector (yellow)
                                                            from airbag main harness located at front pillar
A: REMOVAL AND INSTALLATION                                 lower (both sides).
                                                            9) Detach clips (A) from steering support beam
1) Turn ignition switch off.                                and remove main harness.
2) Disconnect ground cable from battery and wait
for at least 20 seconds before starting work.
3) Remove lower cover.
4) Disconnect airbag connector (AB3) and (AB8)
below steering column.
CAUTION:
Do not reconnect airbag connector at steering
column until main harness are securely re-in-
stalled.

                                                                                                    H5M0933B

                                                            10) Install in the reverse order of removal.




                                         G5M0312

5) Remove instrument panel.
6) Disconnect connector from airbag control mod-
ule.




                                         S5M0216

7) Disconnect body harness connector (B31) from
airbag connector (AB1) located at front pillar lower
(driver side).




                                        S5M0217A
