Image preview - the first page of the document
for3_body_1


>> Download for3_body_1 documenatation <<

Text preview - extract from the document
2003 FORESTER SERVICE MANUAL                                      QUICK REFERENCE INDEX

BODY SECTION

                                               HVAC SYSTEM                     AC
                                               (HEATER, VENTILATOR AND A/C)

                                               HVAC SYSTEM (AUTO A/C)          AC
                                               (DIAGNOSTICS)

                                               AIRBAG SYSTEM                   AB


                                               AIRBAG SYSTEM (DIAGNOSTICS)     AB
  This service manual has been prepared
  to provide SUBARU service personnel
                                               SEAT BELT SYSTEM                SB
  with the necessary information and data
  for the correct maintenance and repair
  of SUBARU vehicles.                          LIGHTING SYSTEM                 LI
  This manual includes the procedures
  for maintenance, disassembling, reas-
  sembling, inspection and adjustment of       WIPER AND WASHER SYSTEMS        WW
  components and diagnostics for guid-
  ance of experienced mechanics.
  Please peruse and utilize this manual        ENTERTAINMENT                   ET
  fully to ensure complete repair work for
  satisfying our customers by keeping
  their vehicle in optimum condition.          COMMUNICATION SYSTEM            COM
  When replacement of parts during
  repair work is needed, be sure to use
  SUBARU genuine parts.                        GLASS/WINDOWS/MIRRORS           GW


                                               BODY STRUCTURE                  BS


                                               INSTRUMENTATION/DRIVER INFO     IDI


                                               SEATS                           SE


                                               SECURITY AND LOCKS              SL


                                               IMMOBILIZER (DIAGNOSTICS)       IM

                                               SUNROOF/T-TOP/CONVERTIBLE TOP   SR
                                               (SUNROOF)
  All information, illustration and specifi-
  cations contained in this manual are         EXTERIOR/INTERIOR TRIM          EI
  based on the latest product information
  available at the time of publication
  approval.

            FUJI HEAVY INDUSTRIES LTD.                                               G8070GE6
2003 FORESTER SERVICE MANUAL              QUICK REFERENCE INDEX

BODY SECTION


                           EXTERIOR BODY PANELS     EB


                           CRUISE CONTROL SYSTEM    CC

                           CRUISE CONTROL SYSTEM    CC
                           (DIAGNOSTICS)




                                                         G8070GE6
HVAC SYSTEM
(HEATER, VENTILATOR AND A/C)

                                                                                                   AC
                                                                                                                      Page
         1.   General Description ....................................................................................2
         2.   Refrigerant Pressure with Manifold Gauge Set.........................................25
         3.   Refrigerant Recovery Procedure...............................................................26
         4.   Refrigerant Charging Procedure ...............................................................27
         5.   Refrigerant Leak Check ............................................................................30
         6.   Compressor Oil .........................................................................................32
         7.   Blower Motor Unit Assembly .....................................................................33
         8.   Blower Resistor (Manual A/C Model) ........................................................34
         9.   Heater Core...............................................................................................35
        10.   Control Unit ...............................................................................................36
        11.   Compressor...............................................................................................37
        12.   Condenser.................................................................................................39
        13.   Condenser Fan (Sub Fan) ........................................................................40
        14.   Heater Cooling Unit...................................................................................41
        15.   Evaporator.................................................................................................42
        16.   Hose and Tube..........................................................................................43
        17.   Relay and Fuse .........................................................................................44
        18.   Pressure Switch (Triple Pressure Switch).................................................45
        19.   Ambient Sensor (Auto A/C Model) ............................................................46
        20.   Sun-load Sensor (Auto A/C Model)...........................................................47
        21.   Air Vent Grille ............................................................................................48
        22.   Heater Duct ...............................................................................................49
        23.   Heater Vent Duct.......................................................................................50
        24.   General Diagnostics..................................................................................51
                                         GENERAL DESCRIPTION
HVAC SYSTEM (HEATER, VENTILATOR AND A/C)

1. General Description
A: SPECIFICATIONS
1. HEATER SYSTEM
                    Item                           Specifications                           Condition
