Image preview - the first page of the document



>> Download for3_sec1_4-2 documenatation <<

Text preview - extract from the document

                                    TIMING BELT ASSEMBLY
MECHANICAL

15.Timing Belt Assembly
A: REMOVAL
1. TIMING BELT
1) Remove the V-belt.
2) Remove the crankshaft pulley.
3) Remove the belt cover.
4) Remove the timing belt guide. (MT vehicles)




                                                                                               ME-00232
                                       ME-00230
                                                        (2) Using white paint, put alignment and/or ar-
5) If the alignment mark (a) and/or arrow mark          row marks on the timing belts in relation to crank
(which indicates rotation direction) on timing belt     sprocket and cam sprockets.
fade away, put new marks before removing the tim-
ing belt as shown in procedures below.
   (1) Turn the crankshaft using ST. Align the
   mark (a) of sprocket to cylinder block notch (b)
   and ensure the right side cam sprocket mark (c),
   cam cap and cylinder head matching surface (d)
   and/or left side cam sprocket mark (e) and belt
   cover notch (f) are properly adjusted.
ST 499987500         CRANKSHAFT SOCKET

                                                                                               ME-00233

                                                      Specified data:
                                                        Z1: 46.8 tooth length
                                                        Z2: 43.7 tooth length



                                                                      Z1                  Z2
                                       ME-00231




                                                                                               ME-000234

                                                      6) Remove the belt idler (No. 2).




                                            ME(SOHC)-46
                                    TIMING BELT ASSEMBLY
                                                                                           MECHANICAL

7) Remove the belt idler No. 2.                     B: INSTALLATION
                                                    1. AUTOMATIC BELT TENSION ADJUST-
                                                    ER ASSEMBLY AND BELT IDLER
                                                    1) Preparation for installation of automatic belt ten-
                                                    sion adjuster assembly;
                                                    CAUTION:
