Image preview - the first page of the document



>> Download for3_sec2_1-2 documenatation <<

Text preview - extract from the document

2003 FORESTER SERVICE MANUAL                                     QUICK REFERENCE INDEX

ENGINE 2 SECTION


                                                FUEL INJECTION (FUEL SYSTEMS)     FU(TURBO)


                                                EMISSION CONTROL                  EC(TURBO)
                                                (AUX. EMISSION CONTROL DEVICES)

                                                INTAKE (INDUCTION)                IN(TURBO)


                                                MECHANICAL                        ME(TURBO)
   This service manual has been prepared
   to provide SUBARU service personnel
                                                EXHAUST                           EX(TURBO)
   with the necessary information and data
   for the correct maintenance and repair
   of SUBARU vehicles.                          COOLING                           CO(TURBO)
   This manual includes the procedures
   for maintenance, disassembling, reas-
   sembling, inspection and adjustment of       LUBRICATION                       LU(TURBO)
   components and diagnostics for guid-
   ance of experienced mechanics.
   Please peruse and utilize this manual        SPEED CONTROL SYSTEMS             SP(TURBO)
   fully to ensure complete repair work for
   satisfying our customers by keeping
   their vehicle in optimum condition.          IGNITION                          IG(TURBO)
   When replacement of parts during
   repair work is needed, be sure to use
   SUBARU genuine parts.                        STARTING/CHARGING SYSTEMS         SC(TURBO)


                                                ENGINE(DIAGNOSTICS)               EN(TURBO)




   All information, illustration and specifi-
   cations contained in this manual are
   based on the latest product information
   available at the time of publication
   approval.

             FUJI HEAVY INDUSTRIES LTD.                                                  G8070GE3
                          WASTEGATE CONTROL SOLENOID VALVE
FUEL INJECTION (FUEL SYSTEMS)

15.Wastegate Control Solenoid                         6) Remove the wastegate control solenoid valve
                                                      from bracket.
   Valve
A: REMOVAL
1) Disconnect the ground cable from battery.




                                                                                                 FU-00368

                                                      B: INSTALLATION
                                                      Install in the reverse order of removal.
                                          FU-00009
                                                      Tightening torque:
2) Disconnect the engine harness connector (A)          6.4 N
