                            ELECTRICAL COMPONENTS LOCATION
CRUISE CONTROL SYSTEM (DIAGNOSTICS)

3. Electrical Components Location
A: LOCATION
                                                                           (2)




             (1)




                                              (3)




                   (4)




                          (5)     (6)


                                               (7)
                                                                                                               CC-00001

 (1)   Actuator                         (4)   Cruise control main switch         (7)   Cruise control module
 (2)   Inhibitor switch (AT model)      (5)   Clutch switch (MT model)
 (3)   Cruise control command switch    (6)   Stop and brake switch




                                                    CC(H4SO)-6
