Image preview - the first page of the document



>> Download Roof Rail documenatation <<

Text preview - extract from the document

                                              ROOF RAIL
                                                                                  EXTERIOR/INTERIOR TRIM

13.Roof Rail
A: REMOVAL
1) Remove the roof trim.
2) Remove the five mounting nuts.
3) Detach the clip at front edge sideways carefully to remove the roof rail upwards.



                                                                                                   B
                                                                                               A
                                                                                       A
                                                                              A
                                                                         A

                                                                     C




                   A                                 B                                     C




                                                                                           a




                                                                                                       EI-00058

NOTE:
Remove the clip at "C" area upwards while applying sideway force to deflect hook at "a" area.
B: INSTALLATION
Install in the reverse order of removal.
CAUTION:
Be careful not to scratch the body panels with
roof rail stud bolts when removing and install-
ing them.
Tightening torque:
  7.5 N
