Image preview - the first page of the document
Rear Inner Remote


>> Download Rear Inner Remote documenatation <<

Text preview - extract from the document
                                           REAR INNER REMOTE
                                                               SECURITY AND LOCKS

9. Rear Inner Remote
A: REMOVAL
1) Remove the rear door trim.
2) Remove the sealing cover.
3) Remove a screw and two cables.
4) Remove the inner remote.




                                           SL-00007

B: INSTALLATION
Install in the reverse order of removal.
NOTE:
Make sure the inner remote works properly after in-
stallation.
C: INSPECTION
1) Make sure the cable is not deformed.
2) Make sure the lever and cable work smoothly.
3) Make sure that the rear door child safety lock op-
erates properly.
NOTE:
If the remote handle is metalclad type, make sure
that grease is sufficiently applied to the cable con-
nection portion.
If the grease is insufficient, apply additional grease
to the cable connection portion before connecting
the cable.




                                                      SL-31
                                       REAR OUTER HANDLE
SECURITY AND LOCKS

10.Rear Outer Handle
A: REMOVAL
1) Remove the rear door trim.
CAUTION:
Do not use excessive force to remove the door
panel. This will deform it.
2) Remove the sealing cover.
3) Remove the rear inner remote.
4) Remove the rear door latch assembly.
5) Remove two bolts, and then remove the rear
outer handle.




                                           SL-00013

B: INSTALLATION
Install in the reverse order of removal.
NOTE:
Make sure the outer handle works properly after in-
stallation.
C: INSPECTION
1) Make sure the resinous lever is not deformed,
damaged or cracked.
2) Make sure the resinous lever operates smoothly.




                                                      SL-32
