>> Download General Description documenatation <<Text preview - extract from the document GENERAL DESCRIPTION
WIPER AND WASHER SYSTEMS
1. General Description
A: SPECIFICATIONS
Front wiper motor Input 12 V -- 72 W or less
Rear wiper motor Input 12 V -- 42 W or less
Pump type Centrifugal
Front washer motor
Input 12 V -- 36 W or less
Pump type Centrifugal
Rear washer motor
Input 12 V -- 36 W or less
B: COMPONENT
1. FRONT WIPER
T1
T1
T1
T2
(5)
(4)
T2
T1 (1) (3)
(1)
(3) (2)
(2)
WW-00195
(1) Wiper rubber (4) Wiper rink Tightening torque: N
