>> Download Cylinder Head Assembly documenatation <<Text preview - extract from the document CYLINDER HEAD ASSEMBLY
MECHANICAL
20.Cylinder Head Assembly 13) Remove the bolts (c) and (f) to remove cylinder
head.
A: REMOVAL
1) Remove the intake manifold.
2) Remove the V-belt. (c)
3) Remove the crank pulley.
(d)
4) Remove the timing belt cover.
(b)
5) Remove the timing belt assembly. 14) Remove the cylinder head gasket.
6) Remove the cam sprocket.
Do not scratch the mating surface of cylinder
7) Remove the bolt which installs A/C compressor head and cylinder block.
bracket on cylinder head.
8) Disconnect the PCV hose, then remove the 15) Similarly, remove the right side cylinder head.
rocker cover. 1) Install the cylinder head and gaskets on cylinder
9) Remove the valve rocker assembly. CAUTION:
