>> Download Fuel Pressure documenatation <<Text preview - extract from the document FUEL PRESSURE
MECHANICAL
7. Fuel Pressure Fuel pressure
Standard: 284 -- 314 kPa (2.9 -- 3.2 kg/cm2,
A: INSPECTION 41 -- 46 psi)
WARNING:
Before removing the fuel pressure gauge, lower
the fuel pressure.
NOTE:
If out of specification, check or replace the pressure
regulator and pressure regulator vacuum hose.
1) Lower the fuel pressure.
2) Open the fuel filler flap lid, and then remove the ME-00198
fuel filler cap. 7) After connecting the pressure regulator vacuum
3) Disconnect the fuel delivery hoses from fuel fil- hose, measure the fuel pressure.
ter, and then connect the fuel pressure gauge.
Fuel pressure
Standard: 206 -- 235 kPa (2.1 -- 2.4 kg/cm2,
30 -- 34 psi)
FU-00208
4) Connect the connector of fuel pump relay.
ME-00198
NOTE:
The fuel pressure gauge registers 10 to 20 kPa (0.1
to 0.2 kg/cm2, 1 to 3 psi) higher than standard val-
ues during high-altitude operations.
FU-00262
5) Start the engine.
6) Measure the fuel pressure while disconnecting
the pressure regulator vacuum hose from intake
manifold.
ME(H4SO)-30
