Image preview - the first page of the document



>> Download Transmission Case documenatation <<

Text preview - extract from the document

                                       TRANSMISSION CASE
MANUAL TRANSMISSION AND DIFFERENTIAL

15.Transmission Case                                   7) Remove the drive pinion shaft assembly from left
                                                       side transmission case, and then remove the main
A: REMOVAL                                             shaft assembly.
1) Remove the manual transmission assembly             NOTE:
from vehicle.
2) Remove the clutch release lever.                            (B)

3) Remove the transfer case with extension case
assembly.
4) Remove the bearing mounting bolts.



                                                                                                 MT-00161

                                                              (A) Main shaft assembly
                                                              (B) Drive pinion shaft assembly

                                                       8) Remove the differential assembly.
                                                       NOTE:
                                        MT-00158
