Image preview - the first page of the document
Transmission Mounting System


>> Download Transmission Mounting System documenatation <<

Text preview - extract from the document
                            TRANSMISSION MOUNTING SYSTEM
MANUAL TRANSMISSION AND DIFFERENTIAL

4. Transmission Mounting Sys-                         8) Remove the rear crossmember.
   tem
A: REMOVAL
1. PITCHING STOPPER
1) Disconnect the ground cable from battery.
2) Remove the air intake duct and cleaner case.
3) Remove the air intake duct. (Non-turbo model)

4) Remove the air cleaner case. (Non-turbo model)                                           MT-00079
                                                9) Remove the rear cushion rubber.
5) Remove the intercooler (Turbo model).
6) Remove the pitching stopper.                       1. PITCHING STOPPER
                                                      1) Install the pitching stopper.
                                                      Tightening torque:
                                                        T1: 50 N
