Image preview - the first page of the document
Rear Vehicle Speed Sensor


>> Download Rear Vehicle Speed Sensor documenatation <<

Text preview - extract from the document
                                REAR VEHICLE SPEED SENSOR
AUTOMATIC TRANSMISSION

15.Rear Vehicle Speed Sensor                          B: INSTALLATION
A: REMOVAL                                            1. NON-TURBO MODEL
1. NON-TURBO MODEL                                    When installing the rear vehicle speed sensor, refer
                                                      to "Front Vehicle Speed Sensor."
fer to "Front Vehicle Speed Sensor."              2. TURBO MODEL
2. TURBO MODEL                                        Install in the reverse order of removal.
1) Set the vehicle on a lift.                         NOTE:
2) Disconnect the ground cable from battery.          Replace the O-ring with a new one.
3) Lift-up the vehicle.                               Tightening torque:
4) Disconnect the rear vehicle speed sensor con-        7 N
