Image preview - the first page of the document
Transfer Duty Solenoid and Valve Body


>> Download Transfer Duty Solenoid and Valve Body documenatation <<

Text preview - extract from the document
                      TRANSFER DUTY SOLENOID AND VALVE BODY
                                                                                      AUTOMATIC TRANSMISSION

20.Transfer Duty Solenoid and                                    10) Remove the heat shield cover. (If equipped)
                                                                 11) Remove the propeller shaft.
A: REMOVAL                                                       12) Remove the transmission rear crossmember.
1) Set the vehicle on a lift.                                       (1) Support the transmission using a transmis-
2) Disconnect the ground cable from battery.                        sion jack and raise slightly.
3) Remove the air cleaner case. (Non-turbo model)                   (2) Remove the bolts and nuts as shown in the

4) Remove intercooler. (Turbo model)

5) Remove the pitching stopper.




                                                                                                       AT-00024

                                                                 13) Remove the rear vehicle speed sensor.



                                                  AT-00023

6) Remove the front exhaust pipe with center ex-
haust pipe. (Non-turbo model)

7) Remove center exhaust pipe. (Turbo model)

8) Remove the rear exhaust pipe and muffler.                     14) Remove the select cable nut.
(Non-turbo model)

(Turbo model)

9) Raise the vehicle and drain the ATF.

                                                                                                       AT-00083
                             (B)            (A)
                                                                 15) Move the gear select cable so that bolts which
                                                                 are securing the extension case can be removed.
                                                                 16) Remove the bolts.


          (C)

                                                  AT-00016

      (A) Oil pan
      (B) Drain plug (ATF)
      (C) Deferential gear oil drain plug



                                                             4AT-73
                      TRANSFER DUTY SOLENOID AND VALVE BODY
AUTOMATIC TRANSMISSION

17) Remove the extension case.                              B: INSTALLATION
NOTE:                                                       1) Install the transfer duty solenoid and transfer
Use a container to catch oil flowing from extension.        valve body.
                                                               (1) Install the transfer duty solenoid and trans-
                                                               fer valve body.
                                                            Tightening torque:
                                                              8 N
