Transmission Mounting System


>> Download Transmission Mounting System documenatation <<

Text preview - extract from the document
                           TRANSMISSION MOUNTING SYSTEM
                                                                            AUTOMATIC TRANSMISSION

10.Transmission Mounting Sys-                        7) Remove the transmission rear crossmember.
   tem
A: REMOVAL
1. PITCHING STOPPER
1) Disconnect the ground cable from battery.
2) Remove the air cleaner case. (Non-turbo model)

3) Remove the intercooler. (Turbo model)                                                   AT-00024
                                                 8) Remove the rear cushion rubber.
4) Remove the pitching stopper.                      B: INSTALLATION
                                                     1. PITCHING STOPPER
                                                     1) Install the pitching stopper.
                                                     Tightening torque:
                                                       T1: 50 N
