Image preview - the first page of the document
>> Download Transmission Control Module (TCM) documenatation <<
Text preview - extract from the document
TRANSMISSION CONTROL MODULE (TCM)
AUTOMATIC TRANSMISSION
22.Transmission Control Mod- 5) Remove the transmission control module.
ule (TCM)
A: REMOVAL (A)
1) Disconnect the ground cable from battery.
(B)
AT-00454
(A) Transmission control module
(B) Brake pedal
AT-00041
B: INSTALLATION
2) Remove the lower cover and then disconnect 1) Install the transmission control module.
the connector.
3) Remove the knee bolster. Tightening torque:
