Image preview - the first page of the document
>> Download 06. V-belt documenatation <<
Text preview - extract from the document
V-BELT
PERIODIC MAINTENANCE SERVICES
6. V-belt Belt tension
(A) 490 -- 640 N (50 -- 65 kgf, 110 -- 144 lb)
A: INSPECTION (B) 350 -- 450 N (36 -- 46 kgf, 79 -- 101 lb)
1. WITHOUT USING BELT TENSION (A)
GAUGE
P/S GEN A/C
1) Replace the belts, if cracks, fraying or wear is
(B)
found.
2) Check the V-belt tension and adjust it if neces-
sary by changing the generator installing position
and/or idler pulley installing position.
C/P
Belt tension PM-00154
(A)
Replaced: 7 -- 9 mm (0.276 -- 0.354 in)
(A) Front side belt
Reused: 9 -- 11 mm (0.354 -- 0.433 in)
(B) Rear side belt
(B)
C/P Crank pulley
Replaced: 7.5 -- 8.5 mm (0.295 -- 0.335 in)
GEN Generator
Reused: 9.0 -- 10.0 mm (0.354 -- 0.394 in)
P/S Power steering oil pump pulley
98 N (10kg) A/C A/C compressor pulley
I/P Idler pulley
P/S GEN A/C
(A) (B)
B: REPLACEMENT
1. V-BELT COVER
Remove the V-belt cover.
I/P NON-TURBO MODEL
C/P
PM-00002
(A) Front side belt
(B) Rear side belt
C/P Crankshaft pulley
GEN Generator
P/S Power steering oil pump pulley
A/C Air conditioning compressor pulley
I/P Idler pulley PM-00003
2. WITH USING BELT TENSION GAUGE TURBO MODEL
1) Replace the belts, if cracks, fraying or wear is
found.
2) Remove the V-belt cover and radiator reservoir
tank.
3) Check the belt tension using belt tension gauge.
And adjust it if necessary by changing the genera-
tor installing position and/or idler pulley installing
position.
SC-00096
PM-9
V-BELT
PERIODIC MAINTENANCE SERVICES
2. FRONT SIDE BELT (DRIVING POWER 7) Install the front side belt.
STEERING OIL PUMP AND GENERATOR) Non-turbo model
Wipe off any oil or water on the belt and pulley. Turbo model
1) Loosen the lock bolt (A).
3) Remove the front side belt (C).
4) Install a new belt, and tighten the slider bolt so as Tightening torque:
to obtain the specified belt tension. 23 N ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
