Image preview - the first page of the document



>> Download 15. ATF documenatation <<

Text preview - extract from the document

                                                          ATF
PERIODIC MAINTENANCE SERVICES

15.ATF                                                        7) Check the ATF for leaks.
                                                              Check for leaks in the transmission. If there are
A: INSPECTION                                                 leaks, it is necessary to repair or replace gasket, oil
CAUTION:                                                      seals, plugs or other parts.
The level of ATF varies with fluid temperature.               B: REPLACEMENT
Pay attention to the fluid temperature when
checking ATF level.                                           1. AUTOMATIC TRANSMISSION FLUID
1) Raise the ATF temperature by driving a distance            1) Drain the ATF (Automatic Transmission Fluid)
of 5 to 10 km (3 to 6 miles). Otherwise, idle the en-         by removing drain plug.
gine to raise ATF temperature to 70 -- 80
