Image preview - the first page of the document
>> Download 16. Front & Rear Differential Gear Oil documenatation <<
Text preview - extract from the document
FRONT & REAR DIFFERENTIAL GEAR OIL
PERIODIC MAINTENANCE SERVICES
16.Front & Rear Differential Gear 3) Fill differential gear oil through the oil level
gauge hole up to the upper point of level gauge.
Oil
NOTE:
A: REPLACEMENT Each oil manufacturer has its base oil and addi-
tives. Thus, do not mix two or more brands.
1. FRONT DIFFERENTIAL (MT MODEL)
Differential gear oil capacity:
For MT vehicle, differential oil works as manual
1.1 -- 1.3 2 (1.2 -- 1.4 US qt, 1.0 -- 1.1 lmp qt)
transmission oil to lubricate differential. Refer to
"Transmission Oil".
2. FRONT DIFFERENTIAL (AT MODEL) (B) (A)
1) Drain the differential gear oil by removing drain (C)
plug using TORX ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
