Image preview - the first page of the document



>> Download 19. Disc Brake Pads and Discs documenatation <<

Text preview - extract from the document

                                      DISC BRAKE PADS AND DISCS
                                                                           PERIODIC MAINTENANCE SERVICES

19.Disc Brake Pads and Discs
                                                                                            (A)
A: INSPECTION                                                                      (C)
                                                                                                    (B)
1. DISC BRAKE PAD AND DISC
1) Jack-up the vehicle and support with rigid racks.
Then remove the wheels.
2) Visually check the pad thickness through inspec-
tion hole of disc brake assembly. Replace the pad if
necessary.
                                                                                                          PM-00140
NOTE:
When replacing a pad, always replace the pads for
                                                                   (1) Thickness of pad
both the right and left wheels at the same time. Also
replace the pad clips if they are twisted or worn.                 (2) Back metal
                                                                   (3) Lining

                                                           3) Check the disc rotor, and correct or replace if it is
                                                           damaged or worn.
