Image preview - the first page of the document
>> Download 11. Cooling System documenatation <<
Text preview - extract from the document
COOLING SYSTEM
PERIODIC MAINTENANCE SERVICES
11.Cooling System NOTE:
Rust or dirt on the cap may prevent the valve from
A: INSPECTION functioning normally: be sure to clean the cap be-
1) Check the radiator for leakage, filling it with cool- fore testing.
ant and attach the radiator cap tester (A) to filler Raise the pressure until the needle of gauge stops
neck. Then apply a pressure. and see if the pressure can be retained for 5 to 6
Check the following points: seconds. The radiator cap is normal if a pressure
Non-turbo model above the service limit value has been maintained
157 kPa (1.6 kg/cm2, 23 psi) for this period.
Turbo model Radiator cap valve open pressure
122 kPa (1.2 kg/cm2, 18 psi) Non-turbo model
