Image preview - the first page of the document



>> Download 12. Coolant documenatation <<

Text preview - extract from the document

                                                   COOLANT
PERIODIC MAINTENANCE SERVICES

12.Coolant                                              case. Always use SUBARU Genuine Coolant,
                                                        since other coolant may cause corrosion.
A: REPLACEMENT                                          10) Securely install the radiator cap.
1. REPLACEMENT OF COOLANT                               11) Run the engine for more than 5 minutes at
                                                        2,000 to 3,000 rpm. (Run the engine until radiator
WARNING:                                                becomes hot in order to purge the air trapped in
The radiator is of the pressurized type. Do not         cooling system.)
attempt to open the radiator cap immediately            12) Stop the engine and wait until coolant temper-
after the engine has been stopped.                      ature lowers. Then open the radiator cap to check
1) Lift-up the vehicle.                                 coolant level and add coolant up to radiator filler
2) Remove the under cover.                              neck. Next, add coolant into reservoir tank up to
                                                        "FULL" level.
3) Place a container under drain pipe.
                                                        13) After adding coolant, securely install the radia-
4) Loosen and remove the drain cock to drain en-
                                                        tor and reservoir tank caps.
gine coolant into container.
                                                        2. RELATIONSHIP OF SUBARU COOLANT
                                                        CONCENTRATION AND FREEZING TEM-
                                                        PERATURE
                                                        The concentration and safe operating temperature
                                                        of the SUBARU coolant is shown in the diagram.
                                                        Measuring the temperature and specific gravity of
                                                        the coolant will provide this information.
                                                        [Example]
                                                        If the coolant temperature is 25
