26. Supplemental Restraint System


>> Download 26. Supplemental Restraint System documenatation <<

Text preview - extract from the document
                           SUPPLEMENTAL RESTRAINT SYSTEM
                                                                        PERIODIC MAINTENANCE SERVICES

26.Supplemental Restraint System
A: INSPECTION
Check the airbag system in accordance with the result of the self-diagnosis.
1) Ensure that airbag connectors are connected. If not, properly connect. When the ignition switch is turned
ON with the connector(s) disconnected, the airbag warning light blinks to identify the fault.




                                                                                                     PM-00158

2) Turn the ignition switch ON, and connect the airbag diagnosis terminal of the service connector (located
below lower cover) to the ground terminal.
3) The warning light blinks to indicate a DTC (a fault is identified). When the airbag system is in good order
(no trouble codes are stored in the memory), the warning light blinks on and off at 0.6 second intervals (as
long as the diagnosis terminal is connected to the ground terminal).
4) When the warning light indicates a DTC, check the airbag system in accordance with the troubleshooting
procedure.




                                                  PM-41
                     SUPPLEMENTAL RESTRAINT SYSTEM
PERIODIC MAINTENANCE SERVICES




                                 PM-42
