Image preview - the first page of the document
>> Download 20. Parking Brake documenatation <<
Text preview - extract from the document
PARKING BRAKE
PERIODIC MAINTENANCE SERVICES
20.Parking Brake Brake drum inside diameter
Except for STi model
A: INSPECTION Standard value: 170 mm (6.69 in)
Inspect the brake linings and drums of both sides of Wear limit: 171 mm (6.73 in)
the rear brake at the same time by removing brake STi model
drums. Standard value: 190 mm (7.48 in)
1) Inspect the brake shoes for damage or deforma- Wear limit: 191 mm (7.52 in)
tion and check brake linings for wear.
NOTE:
Always replace both primary and secondary brake
shoes for the right and left wheels at the same time. (B)
Brake lining thickness (except back metal)
Standard value: 3.2 mm (0.126 in)
Wear limit: 1.5 mm (0.059 in)
(A)
PM-00055
(A) Inside diameter
(A) (B) Disk
3) If the deformation or wear of back plate, shoe,
etc. is noticeable, replace them.
(B) 4) When the shoe return spring tension is exces-
(C)
PM-00054 sively weakened, replace it.
B: ADJUSTMENT
(A) Forward
For rear disc brake, adjust the parking brake after
(B) Brake shoe (Primary side)
bleeding air.
(C) Brake shoe (Secondary side) 1) Remove the rear cover (rubber) installed at back
2) Check the disk rotor for wear, dents or other plate.
damage. If the inside surface of disk rotor is 2) Turn the adjuster toward arrow mark (upward)
streaked, correct the surface with emery cloth until it is locked slightly, by using a flat tip screwdriv-
(#200 or more). If it is unevenly worn or tapered, er as shown in illustration.
correct or replace it.
(A)
(B)
(C)
PM-00056
(A) Adjuster
(B) Cover (rubber)
(C) Back plate
3) Turn back (downward) the adjuster 3 to 4 notch-
es.
4) Install the cover (rubber) at original position cor-
rectly.
PM-32
