Image preview - the first page of the document
>> Download 21. Suspension documenatation <<
Text preview - extract from the document
SUSPENSION
PERIODIC MAINTENANCE SERVICES
21.Suspension NOTE:
When the transverse link ball joint has been re-
A: INSPECTION moved or replaced, check the toe-in of front wheel.
1. SUSPENSION BALL JOINT If the front wheel toe-in is not at specified value, ad-
just the toe-in.
1) Jack-up the vehicle until front wheels are off
ground.
2) Next, grasp the bottom of tire and move it in and
out. If relative movement (B) is observed between (A)
the brake disc cover (A) and end of transverse link
(D), ball joint (C) may be excessively worn.
PM-00059
(A) Dust seal
(A)
(D) 2. TRANSVERSE LINK'S REAR BUSHING
(C) (B)
PM-00057 Check oil leaks at around liquid-filled bushing. If oil
leaks, replace the bushing.
3) Next, grasp the end of transverse link and move
it up and down. Relative movement (A) between
the housing (D) and transverse link (C) boss indi- (A)
cates ball joint (B) may be excessively worn.
(D)
(B)
PM-00060
(A)
(C) (A) Rear bushing
(B) (B) Transverse link
PM-00058
4) If relative movement is observed in the immedi- 3. WHEEL ARCH HEIGHT
ately preceding two steps, remove and inspect the 1) Unload cargoes and set the vehicle in curb
ball joint. If free play exceeds standard, replace the weight (empty) condition.
ball joint. 2) Then, check the wheel arch height of front and
5) Damage of dust seal rear suspensions to ensure that they are within
Visually inspect the ball joint dust seal. If it is dam- specified values.
aged, remove the transverse link. And measure free play of visually inspect the following components and re-
ball joint. place deformed parts.
(1) When looseness exceeds standard value, ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
