Image preview - the first page of the document
>> Download 22. Wheel Bearing documenatation <<
Text preview - extract from the document
WHEEL BEARING
PERIODIC MAINTENANCE SERVICES
22.Wheel Bearing 2. REAR WHEEL BEARING
A: INSPECTION 1) Jack-up the rear of vehicle.
2) While holding the rear wheel by hand, swing it in
1. FRONT WHEEL BEARING and out to check bearing free play.
3) Loosen the wheel nuts and remove rear wheel.
NOTE: 4) If the bearing free play exists in step 2) above,
Inspect the condition of front wheel bearing grease. attach a dial gauge to the hub COMPL and mea-
1) Jack-up the front of vehicle. sure axial displacement in axial direction.
2) While holding the front wheel by hand, swing it in
and out to check bearing free play. Service limit:
3) Loosen the wheel nuts and remove front wheel. Straight-ahead position within 0.05 mm
4) If bearing free play exists in step 2) above, at- (0.0020 in)
tach a dial gauge to the hub and measure axial dis- 5) Remove the DOJ of rear drive shaft from rear dif-
placement in axial direction. ferential.
6) While supporting the rear drive shaft horizontally
Service limit: with one hand, turn the hub COMPL with the other
Straight-ahead position within 0.05 mm to check for noise or binding.
(0.0020 in) If the hub COMPL is noisy or binds, disassemble
5) Remove the bolts and self-locking nuts, and ex- the rear axle and check condition of oil seals, bear-
tract transverse link from front crossmember. ings, etc.
6) Remove the SFJ of front drive shaft from trans-
mission. (A)
7) While supporting the front drive shaft horizontal-
(F)
ly with one hand, turn the hub with the other to
(G)
check for noise or binding.
(H)
If the hub is noisy or binds, disassemble the front
axle and check condition of oil seals, bearing, etc. (I)
(B) (C)
(D)
(A) (F) (E)
PM-00062
(G)
(B) (A) Inner oil seal
(B) Rear housing
(C)
(C) Bearing
(D) Snap ring
(D)
(E)
(E) Outer oil seal
PM-00061
(F) Tone wheel
(G) Hub bolt
(A) Inner oil seal
(H) Hub
(B) Snap ring
(I) Socket bolt
(C) Bearing
(D) Housing
(E) Outer oil seal
(F) Hub bolt
(G) Hub
PM-35
