Image preview - the first page of the document
06. Engine Oil Pressure


>> Download 06. Engine Oil Pressure documenatation <<

Text preview - extract from the document
                                        ENGINE OIL PRESSURE
MECHANICAL

6. Engine Oil Pressure
A: INSPECTION
1) Remove the oil pressure switch from engine cyl-
inder block.
2) Connect the oil pressure gauge hose to cylinder
block.
3) Connect the battery ground cable to battery.




                                          FU-00009

4) Start the engine, and then measure the oil pres-
sure.




                                           ME-00009

Oil pressure:
   98 kPa (1.0 kgf/cm2, 14 psi) or more at 800
   rpm
   294 kPa (3.0 kgf/cm2, 43 psi) or more at 5,000
   rpm
