Image preview - the first page of the document
16. Camshaft Sprocket


>> Download 16. Camshaft Sprocket documenatation <<

Text preview - extract from the document
                                    CAMSHAFT SPROCKET
MECHANICAL

16.Camshaft Sprocket                                   B: INSTALLATION
                                                       1) Install the camshaft sprocket. To lock the cam-
A: REMOVAL                                             shaft, use ST.
1) Remove the V-belt.                                         NOTE:
2) Remove the crankshaft pulley.                        during installation.
3) Remove the timing belt cover.                                             WRENCH
4) Remove the timing belt assembly.               98 N
