Image preview - the first page of the document
17. Crankshaft Sprocket


>> Download 17. Crankshaft Sprocket documenatation <<

Text preview - extract from the document
                                      CRANKSHAFT SPROCKET
MECHANICAL

17.Crankshaft Sprocket                                    C: INSPECTION
                                                          1) Check the sprocket teeth for abnormal wear and
A: REMOVAL                                                scratches.
1) Remove the V-belt.                                            et and key.
2) Remove the crankshaft pulley.                           sensor for damage and contamination of foreign
3) Remove the timing belt cover.
4) Remove the timing belt assembly.
5) Remove the camshaft sprocket.
6) Remove the crankshaft sprocket.




                                         ME-00103

B: INSTALLATION
1) Install the crankshaft sprocket.




                                         ME-00103

2) Install the camshaft sprocket.
3) Install the timing belt assembly.
4) Install the timing belt cover.
5) Install the crankshaft pulley.
6) Install the V-belt.




                                                    ME(STi)-56
