Image preview - the first page of the document
>> Download 18. Camshaft documenatation <<
Text preview - extract from the document
CAMSHAFT
MECHANICAL
18.Camshaft 10) Remove the timing belt cover No.2 (RH).
A: REMOVAL
1) Remove the V-belt.
2) Remove the crankshaft pulley.
3) Remove the timing belt cover.
4) Remove the timing belt assembly.
5) Remove the camshaft sprocket. 11) Remove the spark plug cord.
6) Remove the crankshaft sprocket. 13) Remove the rocker cover and gasket.
7) Disconnect the variable valve timing solenoid 14) Remove the oil pipe.
valve assembly connector.
ME-00712
ME-00770
15) Loosen the variable valve timing solenoid valve
8) Remove the tensioner bracket. assembly and intake camshaft cap bolts equally, a
little at a time in alphabetical sequence shown in
the figure.
(A)
(E) (C)
(F) (D)
(B)
ME-00105
9) Remove the timing belt cover No. 2 (LH).
ME-00771
16) Remove the variable valve timing solenoid
valve assembly, intake camshaft cap, and cam-
shaft.
ME-00106
ME(STi)-57
CAMSHAFT
MECHANICAL
17) Loosen the exhaust camshaft cap bolts equal- ◦ Jabse Service Manual Search 2026 ◦ Jabse Pravopis ◦ onTap.bg ◦ Other service manual resources online : Fixya ◦ eServiceinfo
