Image preview - the first page of the document
12. V-belt


>> Download 12. V-belt documenatation <<

Text preview - extract from the document
                                                        V-BELT
                                                                                                     MECHANICAL

12.V-belt                                                    4) Remove the A/C belt tensioner.

A: REMOVAL
1. FRONT SIDE BELT
1) Remove the V-belt cover.




                                                                                                       ME-00061

                                                             B: INSTALLATION
                                                             1. FRONT SIDE BELT
                                            ME-00708         CAUTION:
                                                             Wipe off any oil or water on the belt and pulley.
2) Loosen the lock bolt (A).
3) Loosen the slider bolt (B).                               1) Install the belt (C), and tighten the slider bolt so
4) Remove the front side belt (C).                           as to obtain the specified belt tension
                                                             2) Tighten the lock bolt (A).
       (B)                                                   3) Tighten the slider bolt (B).
                                                (C)          Tightening torque:
                                                               Lock bolt through bolt:
                                                                  25 N
