Image preview - the first page of the document
04. Engine Coolant Temperature Sensor


>> Download 04. Engine Coolant Temperature Sensor documenatation <<

Text preview - extract from the document
                       ENGINE COOLANT TEMPERATURE SENSOR
FUEL INJECTION (FUEL SYSTEMS)

4. Engine Coolant Temperature
   Sensor
A: REMOVAL
1) Disconnect the ground cable from battery.




                                           FU-00009

2) Remove the generator.
3) Drain   the    engine   coolant.
4) Disconnect the connector from the engine cool-
ant temperature sensor.




                                           FU-00055

5) Remove the engine coolant temperature sensor.
B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  18 N
