Image preview - the first page of the document
12. Tumble Generator Valve Actuator


>> Download 12. Tumble Generator Valve Actuator documenatation <<

Text preview - extract from the document
                         TUMBLE GENERATOR VALVE ACTUATOR
                                                                            FUEL INJECTION (FUEL SYSTEMS)

12.Tumble Generator Valve Ac-                              2. LH SIDE
   tuator                                                  1) Release the fuel pressure.
                                                           2) Open the fuel filler lid and remove the fuel filler
1. RH SIDE
                                                           cap.
1) Release the fuel pressure.
2) Open the fuel filler lid and remove the fuel filler
cap.
3) Disconnect the ground cable from battery.




                                                                                                      FU-00009

                                                           4) Disconnect the connector from tumble generator
                                                           valve actuator LH.
                                                           5) Remove the tumble generator valve actuator LH.
                                         FU-00009

4) Remove the intake manifold.
5) Disconnect the connector from tumble generator
valve actuator RH.
6) Remove the tumble generator valve actuator
RH.


                                                                                                      FU-00622

                                                           B: INSTALLATION
                                                           1. RH SIDE
                                                           Install in the reverse order of removal.
                                                           2. LH SIDE
                                         FU-00621          Install in the reverse order of removal.




                                                    FU(STi)-35
