Image preview - the first page of the document



>> Download 13. Wastegate Control Solenoid Valve documenatation <<

Text preview - extract from the document

                          WASTEGATE CONTROL SOLENOID VALVE
FUEL INJECTION (FUEL SYSTEMS)

13.Wastegate Control Solenoid                               6) Remove the wastegate control solenoid valve
                                                            from bracket.
   Valve
A: REMOVAL
1) Disconnect the ground cable from battery.




                                                                                                       FU-00368

                                                            B: INSTALLATION
                                                            Install in the reverse order of removal.
                                          FU-00009
                                                            Tightening torque:
2) Disconnect the engine harness connector (A)                6.4 N
