18. Fuel Pump Relay


>> Download 18. Fuel Pump Relay documenatation <<

Text preview - extract from the document
                                            FUEL PUMP RELAY
                                                                   FUEL INJECTION (FUEL SYSTEMS)

18.Fuel Pump Relay
A: REMOVAL
1) Disconnect the ground cable from battery.




                                           FU-00009

2) Remove the passenger's side front side sill cov-
er.
3) Remove the bolt which holds fuel pump relay
bracket on the body.
4) Disconnect the connector from the fuel pump re-
lay.




                                           ME-00649

5) Remove the fuel pump relay from the mounting
bracket.
B: INSTALLATION
Install in the reverse order of removal.




                                                      FU(STi)-43
