Image preview - the first page of the document



>> Download 29. Fuel Delivery, Return and Evaporation Lines documenatation <<

Text preview - extract from the document

                  FUEL DELIVERY, RETURN AND EVAPORATION LINES
                                                                          FUEL INJECTION (FUEL SYSTEMS)

29.Fuel Delivery, Return and Evaporation Lines
A: REMOVAL
1) Set the vehicle on a lift.
2) Release the fuel pressure.
3) Open the fuel filler flap lid and remove the fuel filler cap.
4) Remove the floor mat.
5) Remove the fuel delivery pipes and hoses, fuel return pipes and hoses, evaporation pipes and hoses.




                                                                                                     FU-00337


6) In engine compartment, detach the fuel delivery        8) Separate the quick connector on the fuel deliv-
hose (A), return hose (B) and evaporation hose (C).       ery line.
                                                             (1) Clean the pipe and connector, if they are
                            (A)                              covered with dust.
                                                             (2) Hold the connector (A) and push retainer (B)
                                  (B)                        down.




            (C)                         FU-00259

7) Lift-up the vehicle.




                                                   FU(STi)-63
                 FUEL DELIVERY, RETURN AND EVAPORATION LINES
FUEL INJECTION (FUEL SYSTEMS)

  (3) Pull out the connector (A) from retainer (B).      NOTE:
                                                         At this time, two clicking sounds are heard.

                                                                          (A)


                                                                                      (B)
                                      (B)


           (A)                              (C)
                                                                                                    (C)



                                      FU-00124
                                                                                                   FU-00126
      (A) Connector
      (B) Retainer                                             (A) Connector
      (C) Pipe                                                 (B) Retainer
                                                               (C) Pipe
B: INSTALLATION
1) Connect the quick connector on the fuel delivery      CAUTION:
line.
