Image preview - the first page of the document



>> Download 11. Pressure Control Solenoid documenatation <<

Text preview - extract from the document

                        PRESSURE CONTROL SOLENOID VALVE
EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

11.Pressure Control Solenoid                            5) Disconnect the connector from pressure control
                                                        solenoid valve.
   Valve
A: REMOVAL
1) Disconnect the ground terminal from battery.




                                                                                              EC-00055

                                                        6) Disconnect the two evaporation hoses from
                                                        pressure control solenoid valve.
                                      FU-00009          7) Remove the pressure control solenoid valve with
2) Remove the canister.
3) Disconnect the evaporation hoses (A) from joint
pipes.




                                                                                              EC-00056

                                                        8) Remove the pressure control solenoid valve
                                                        from bracket.
                                      EC-00053

4) Remove the bolt which installs pressure control
solenoid valve holding bracket on body.




                                                                                              EC-00057

                                                        9) Disconnect the vacuum hose from pressure con-
                                                        trol solenoid valve.
                                      EC-00054




                                                                                              EC-00058




                                                 EC(STi)-12
                          PRESSURE CONTROL SOLENOID VALVE
                                                       EMISSION CONTROL (AUX. EMISSION CONTROL DEVICES)

B: INSTALLATION
Install in the reverse order of removal.
Tightening torque:
  17.6 N
